System And Components
227-8282 LINES GP-DRAFT FRAMES/N DBZ1-UP
Group No: 227-8282
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4T4871 | 1 TUBE AS (RH) | 1 | |
| 4T4872 | 2 TUBE AS (LH) | 1 | |
| 8X8394 | 3 TUBE AS | 1 | |
| 1328617 | 4 VALVE GP-CHECK (CARRY, QUICK-DROP-LH) | 1 | |
| 1328618 | 5 VALVE GP-CHECK (CARRY, QUICK-DROP-RH) | 1 | |
| 1P3704 | 6 SEAL-RECTANGULAR | 5 | |
| 1P5761 | 7 FLANGE-HALF | 6 | |
| 4J0527 | 8 SEAL-O-RING | 2 | |
| 6V8189 | 9 NUT (5/16-18-THD) | 1 | |
| 6V8918 | 10 BOLT (5/16-18X1.25-IN) | 1 | |
| 7X0313 | 11 BOLT (7/16-14X2.75-IN) | 8 | |
| 7X0346 | 12 BOLT (5/8-11X2-IN) | 2 | |
| 7X0351 | 13 BOLT (5/8-11X3.75-IN) | 2 | |
| 8C6877 | 14 BOLT (7/16-14X1.75-IN) | 12 | |
| 8T4122 | 15 WASHER-HARD (17X32X3.5-MM THK) | 4 | |
| 8T4224 | 16 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T5360 | 17 WASHER (12X22.5X2.5-MM THK) | 20 |
