System And Components
199-0631 BOWL GP-SCRAPERS/N DBZ1-UP
Group No: 199-0631
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4J5193 | 1 PIN | 2 | |
| 5J1980 | 2 PIN | 2 | |
| 8T9398 | 3 BOLT (3/4-10X1.75-IN) | 2 | |
| 7X0326 | 4 BOLT (1/2-13X3-IN) | 1 | |
| 8T4223 | 5 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 8W2083 | 6 PIN AS | 1 | |
| 2066318 | 7 BOWL AS | 1 | |
| 3D2365 | 8 CLIP | 8 | |
| 5J2328 | 9 RAIL AS-SIDE | 2 | |
| 4T1274 | 10 RAIL | 2 | |
| 4T5383 | 11 PLATE-WEAR | 2 | |
| 6C3678 | 12 RIVET | 27 | |
| 2284414 | 13 TREAD | 1 | |
| 1U1566 | 14 RIB | 10 | |
| 5P1932 | 15 STRIP-WEAR | 2 | |
| 8W1447 | 16 SUPPORT-EDGE | 1 | |
| 1U4584 | 17 STIFFENER-BOWL | 1 | |
| 4T7667 | 18 REINFORCEMENT | 1 | |
| 9J0262 | 19 BRACKET-PIVOT | 2 | |
| 9J0901 | 20 STIFFENER | 1 | |
| 9J8322 | 21 PIVOT-DRAFT ARM | 2 | |
| 1U4585 | 22 STIFFENER-BOWL (LH)(REAR) | 1 | |
| 4T7668 | 23 REINFORCEMENT | 1 | |
| 9J0902 | 24 STIFFENER (BOWL, LH) | 1 | |
| 4T1241 | 25 HOOK-RETRIEVAL | 2 | |
| 5J2497 | 26 BRACKET | 1 | |
| 8W9786 | 27 PLATE | 1 | |
| 2125009 | 28 BLOCK | 2 | |
| 8X8489 | 29 PLATE | 2 | |
| 0S1621 | 30 BOLT (1/2-13X1-IN) | 4 | |
| 3J2903 | 31 COVER | 1 | |
| 4J0527 | 32 SEAL-O-RING | 1 | |
| 4M5281 | 33 BOLT (1/4-20X0.75-IN) | 6 | |
| 5P8245 | 34 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 6C3060 | 35 GASKET | 1 | |
| 7J5544 | 36 FITTING (3/4X16-THD) | 2 | |
| 8T4205 | 37 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8X1182 | 38 PLUG | 1 | |
| 8X1868 | 39 TUBE AS | 1 | |
| 8X7299 | 40 GASKET | 1 |
