System And Components
234-5005 BASE GP-VALVE COVER & INJ HARNS/N RHX1-1883
Group No: 234-5005 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1233202 | 1 STRAP-CABLE | 3 | |
| 6V0128 | 2 SEAL-CONNECTOR | 1 | |
| 7E6508 | 3 CAP AS | 6 | |
| 9L8925 | 4 BOLT (5/16-18X1.25-IN) | 14 | |
| 1221472 | 5 BOLT (5/16-18X2.36-IN) | 1 | |
| 1774152 | 6 BASE-VALVE MECHANISM COVER | 1 | |
| 2345002 | 7 HARNESS AS-ENGINE (INJECTOR, VARIABLE VALVE) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1038134 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 3S2093 | STRAP-CABLE | 6 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(13-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(15-CM) | ||
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 12 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 12 | |
| 1005218 | 8 CLIP | 3 | |
| 1005219 | 9 CLIP | 3 | |
| 4F7957 | 10 BOLT (1/4-20X0.875-IN) | 2 | |
| 5P0537 | 11 WASHER-HARD (7.2X14.5X2-MM THK) | 8 | |
| 8H3127 | 12 BOLT (1/4-20X0.75-IN) | 6 | |
| 5P5678 | 13 SEAL (3-M) |
