223-7263 CYLINDER HEAD ASS/N RHX1-UP

Group No: 223-7263 · Commonality
Part NumberPart NameQty
12273751 GUIDE-VALVE (STANDARD)(STANDARD)24
1220447GUIDE-VALVE (0.51-MM OS)
1228612GUIDE-VALVE (0.13-MM OS)
21655822 BUSHING (STANDARD)(STANDARD)7
2170751BUSHING (0.25-MM OS)
2170752BUSHING (0.762-MM OS)
2613429BUSHING (1.778-MM OS)
2613430BUSHING (1.27-MM OS)
28039793 INSERT-VALVE SEAT (INLET)(STANDARD)12
22655614 INSERT-VALVE SEAT (EXHAUST)(STANDARD)12
2884883INSERT-VALVE SEAT (0.51-MM OS, EXHAUST)
2884884INSERT-VALVE SEAT (0.76-MM OS, EXHAUST)
26349205 SLEEVE-INJECTOR (INLET)6
16629048 SEAL-O-RING12
3B06239 PLUG-CUP (25.73-MM OD)17
3B064510 PLUG-CUP (32.08-MM OD)20
8T675711 PLUG-PIPE3
9X743012 SEAL-O-RING6
493959113 HEAD-CYLINDER1
4483297HEAD-CYLINDER1
