System And Components
220-3722 LINES GP-AIRS/N DFJ424-UP
Group No: 220-3722
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1862002 | 1 HOSE | 1 | |
| 1094203 | 2 ELBOW | 1 | |
| 1270929 | 3 CLAMP-V BAND | 1 | |
| 2178946 | 4 ELBOW | 1 | |
| 2345861 | 5 TUBE | 1 | |
| 2345862 | 6 TUBE | 1 | |
| 2376480 | 7 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2453572 | 8 HOSE | 1 | |
| 1013125 | 9 GASKET (AIR INLET MANIFOLD) | 1 | |
| 2087448 | 10 CLAMP | 8 | |
| 3J7354 | 13 SEAL-O-RING | 1 | |
| 5C6565 | 14 BOLT (1/2-13X1.125-IN) | 2 | |
| 7E8630 | 15 HOSE-AIR INLET | 2 | |
| 8C3089 | 16 SEAL-O-RING | 1 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4896 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 9B7237 | 19 BOLT (3/8-16X1.25-IN) | 5 | |
| 9S4182 | 20 PLUG (7/16-20-THD) | 1 | |
| 3497285 | 21 BRACKET | 1 | |
| 1984778 | 22 WASHER-HARD (13.5X30X12-MM THK) | 2 | |
| 8T4910 | 23 BOLT (M12X1.75X60-MM) | 1 | |
| 8T4244 | 24 NUT (M12X1.75-THD) | 1 | |
| 7X0732 | 25 WASHER-HARD (10X22.5X8-MM THK) | 1 | |
| 6V6783 | 26 CLIP (TAB) | 1 | |
| 6V6782 | 27 CLIP (SLOT) | 1 | |
| 3E4096 | 28 CAP | 9 |
