247-8137 TANK GP-HYDRAULICS/N DFJ1-365

Group No: 247-8137

Part Number	Part Name	Qty
6G9765	1 TUBE AS	1
1J8595	2 GASKET	1
2G9354	3 COVER AS	1
5D4218	BLOCK	1
2G9356	4 GASKET	1
3D6678	5 STRAINER (METAL)(HYDRAULIC OIL)	1
3G7233	6 FILTER GP-OIL	1
4J3754	7 CAP-FILLER (HYDRAULIC TANK)	1
4J3816	8 PLATE	1
5D1901	9 WASHER (106.5X126.5X2.5-MM THK)	1
5P1717	10 CLAMP-HOSE	4
5P1296	11 HOSE (15-CM)	1
5T0096	12 SCREEN AS (HYDRAULIC TANK)	1
5T4624	13 MOUNTING	1
6G1249	14 GASKET	1
6G9988	15 ELBOW	1
6J1080	16 GROMMET	1
6J1081	17 GLASS-SIGHT (HYDRAULIC OIL LEVEL)	1
2142346	18 PLATE-INDICATOR (HYDRAULIC OIL LEVEL)	1
7B2805	19 RING-LOCK	1
2G9034	20 COVER	1
8L8137	21 CLIP	1
9J8243	22 RETAINER	1
9M7394	23 LEVER	1
1263584	24 TUBE AS	1
1925125	25 ELBOW	1
2478138	26 TANK AS-HYDRAULIC	1
1K4455	BAR	3
8F9836	BOSS (3/8-16-THD)	3
0307335	27 BOLT-LOCKING (5/8-11X1.5-IN)	4
0310219	28 BOLT-LOCKING (3/8-16X1.75-IN)	8
0352017	29 SCREW-BUTTON HEAD (3/8-16X1-IN)	4
0L2070	30 BOLT (3/8-16X2.25-IN)	1
4L6454	31 BOLT (3/8-16X1-IN)	76
1L5072	32 DOWEL	1
1M8649	33 RING-RETAINING	1
2H6338	34 SEAL-O-RING	3
2K4973	35 LOCKNUT (3/8-16-THD)	77
3B0551	36 PLUG-PIPE	1
4B9782	37 BALL	1
4J3815	38 GASKET	1
4P0519	39 ADAPTER AS-DRAIN	1
1095840	ADAPTER-PLUG	1
1095839	PLUG-DRAIN (HYDRAULIC TANK)	1
5D1902	40 COVER-HYDRAULIC CAP	1
5H6005	41 SEAL-O-RING	4
5H8985	42 PIN-SPRING	1
5K7143	43 BOLT-SELF-LOCKING (1/2-13X1.5-IN)	8
5K9107	44 BOLT-LOCKING (3/8-16X0.75-IN)	1
5M2894	45 WASHER-HARD (10.2X18.5X2.5-MM THK)	9
5P8245	46 WASHER-HARD (13.5X25.5X3-MM THK)	10
5P8247	47 WASHER-HARD (17X32X3.5-MM THK)	4
6N8863	48 WASHER (10.2X32X2.5-MM THK)	3
6V3830	49 SEAL-O-RING	1
7F8268	50 SEAL-O-RING	1
9S1366	51 BOLT (1/2-13X2.5-IN)	2
