System And Components
215-9152 CONTROL GP-STEERINGS/N DFJ312-UP
Group No: 215-9152
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3865262 | 1 SHAFT AS | 1 | |
| 2211432 | 2 KIT-COVER (STEERING COLUMN) | 1 | |
| 3089433 | 3 VALVE GP-CHECK | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3092791 | 4 PLATE AS | 1 | |
| 3228568 | 5 BUTTON AS-HORN | 1 | |
| 3399363 | 6 SWITCH AS-MULTIFUNCTION (TURN SIGNAL) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 12 | |
| 1743091 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 3635912 | 7 STEERING WHEEL AS | 1 | |
| 3636423 | PLUG | 1 | |
| 3734568 | 8 STEERING COLUMN GP-ADJUSTABLE | 1 | |
| 1488340 | 9 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488364 | 10 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488411 | 11 PLUG AS | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 1616987 | 12 WASHER-HARD (5.2X16X1.5-MM THK) | 2 | |
| 3B4502 | 13 LOCKWASHER | 2 | |
| 4L6454 | 14 BOLT (3/8-16X1-IN) | 4 | |
| 7X3183 | 16 BOLT (3/8-24X1-IN) | 4 | |
| 9X6615 | 17 BOLT (M5X0.8X30-MM) | 2 | |
| 8T0328 | 18 WASHER-HARD (5.5X10X1-MM THK) | 2 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 |
