System And Components
240-9508 DRIVE GP-FANS/N JRP2759-UP
Group No: 240-9508 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B4617 | 1 PIN-COTTER | 4 | |
| 3272476 | 2 SPRING AS | 1 | |
| 3561073 | 3 V-BELT SET (INCLUDES 4-BELTS)(FAN) | 1 | |
| 2431872 | 4 DRIVE GP-FAN | 1 | |
| 2662365 | 5 BELT TIGHTENER GP | 1 | |
| 2662415 | 6 PULLEY | 1 | |
| 2741762 | 7 PULLEY | 1 | |
| 2747515 | 8 ADAPTER-FAN | 1 | |
| 3234095 | 9 BRACKET AS | 1 | |
| 1S9209 | SHAFT-TIGHTENER | 1 | |
| 8H9189 | DOWEL | 1 | |
| 5P2566 | 11 BOLT (1/2-13X1.5-IN) | 6 | |
| 5S7382 | 12 BOLT (3/8-16X1.375-IN) | 6 | |
| 7X0332 | 13 BOLT (1/2-13X4.5-IN) | 4 | |
| 8T4183 | 14 BOLT (M12X1.75X40-MM) | 4 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 16 | |
| 8T4896 | 16 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 8T9389 | 17 BOLT (1/2-13X2.75-IN) | 4 | |
| 5V9221 | 18 SPACER (13.8X25X25-MM THK) | 2 | |
| 6V8188 | 19 NUT (1/2-13-THD) | 2 | |
| 7V9791 | 20 PIN | 2 | |
| 8N5579 | 21 RETAINER | 2 | |
| 1782255 | 22 PIN | 2 | |
| 3702255 | 23 PLATE | 1 | |
| 3706277 | 24 PLATE | 1 |
