System And Components
231-0211 LINES GP-ENGINE OIL FILTERS/N LJW2110-UP
Group No: 231-0211 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W1116 | 1 BODY-BYPASS | 1 | |
| 2P4305 | 2 GASKET | 2 | |
| 4N0861 | 3 COVER | 1 | |
| 4N0865 | 4 GASKET | 1 | |
| 4N8411 | 5 TUBE-COOLER BYPASS | 1 | |
| 4N8600 | 6 ADAPTER-BASE | 1 | |
| 5G6504 | 7 LUG | 4 | |
| 6G2168 | 8 BLOCK | 1 | |
| 7C9010 | 9 SUPPORT-BASE | 1 | |
| 8C3445 | 10 CAP-DUST | 1 | |
| 9F6304 | 11 SPRING | 2 | |
| 9M0853 | 12 PLUNGER-VALVE | 2 | |
| 2259618 | 13 SUPPORT AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 8 | |
| 2483329 | 14 TUBE AS | 1 | |
| 2483330 | 15 TUBE AS | 1 | |
| 0617540 | 16 SEAL-O-RING | 4 | |
| 0L2070 | 17 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S1571 | 18 BOLT (3/8-16X1.75-IN) | 4 | |
| 0S1590 | 19 BOLT (3/8-16X2-IN) | 6 | |
| 0S1594 | 20 BOLT (3/8-16X1-IN) | 10 | |
| 0S1608 | 21 BOLT (3/8-16X3.75-IN) | 1 | |
| 0T0065 | 22 BOLT (3/8-16X3.5-IN) | 1 | |
| 0T0772 | 23 BOLT (7/16-14X1.5-IN) | 12 | |
| 1515145 | 24 ELBOW | 1 | |
| 1A1460 | 25 BOLT (1/2-13X2-IN) | 4 | |
| 1A2029 | 26 BOLT (3/8-16X1.125-IN) | 4 | |
| 3D2824 | 27 SEAL-O-RING | 1 | |
| 3P0650 | 28 SEAL-O-RING | 3 | |
| 4F5192 | 29 BOLT (7/16-14X3-IN) | 4 | |
| 4J0522 | 30 SEAL-O-RING | 1 | |
| 4N8770 | 31 ELBOW-COOLER OUTLET | 1 | |
| 5M2894 | 32 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 5P8068 | 33 SEAL-O-RING | 1 | |
| 5P8244 | 34 WASHER-HARD (12X22.5X2.5-MM THK) | 16 | |
| 5P8245 | 35 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 5P9890 | 36 SEAL-O-RING | 2 | |
| 6V5048 | 37 SEAL-O-RING | 2 | |
| 8C3446 | 38 VALVE-SAMPLING (ENGINE OIL) | 1 | |
| 9S4183 | 39 PLUG (1-1/16-12-THD) | 1 | |
| 9S8752 | 40 NUT-FULL (3/8-16-THD) | 4 |
