System And Components
248-7694 PUMP & LINES GPS/N JRP1-1628
Group No: 248-7694 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N3925 | 1 EXTENSION GP-DRAIN | 1 | |
| 1235150 | 2 VALVE-CHECK | 1 | |
| 1292327 | 3 ELBOW | 1 | |
| 1488390 | 4 ELBOW AS | 1 | |
| 6V8626 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1532995 | 5 COUPLING (MALE) | 1 | |
| 1569791 | 6 CONNECTOR-SPECIAL | 1 | |
| 1938335 | 7 FITTING AS (QUICK DISCONNECT, FEMALE) | 1 | |
| 2275525 | 8 PUMP & MOTOR GP-HYDRAULIC (SEC STRG, BRK REL, HS OIL CHG)(HIGH SPEED OIL CHANGE, PRELUBE) | 1 | |
| 2490073 | 9 FITTING AS | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 2953482 | 10 HOSE AS | 1 | |
| 2555010 | 11 HOSE AS | 1 | |
| 3004027 | 12 HOSE AS | 1 | |
| 2664637 | 13 BRACKET | 1 | |
| 2416208 | 14 ELBOW AS | 1 | |
| 1196220 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 2M9780 | 15 SEAL-O-RING | 2 | |
| 3D2824 | 16 SEAL-O-RING | 1 | |
| 3K0360 | 17 SEAL-O-RING | 1 | |
| 4S1962 | 18 CLIP (LOOP) | 1 | |
| 5P2211 | 19 ADAPTER (1-1/16-12-THD) | 1 | |
| 6V8189 | 20 NUT (5/16-18-THD) | 2 | |
| 6V8801 | 21 NUT (3/8-16-THD) | 4 | |
| 6V8918 | 22 BOLT (5/16-18X1.25-IN) | 2 | |
| 6V9170 | 23 NUT-BULKHEAD (1-14-THD) | 1 | |
| 7J9108 | 24 SEAL-O-RING | 3 | |
| 8M1047 | 25 STUD-TAPERLOCK (3/8-16X1.67-IN) | 2 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 27 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4137 | 28 BOLT (M10X1.5X20-MM) | 1 | |
| 8T4224 | 29 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 1J8668 | 30 STUD-TAPERLOCK (3/8-16X1.97-IN) | 2 | |
| 8T4896 | 31 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1488352 | 32 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 |
