System And Components
243-5157 AIR CLEANER GPS/N JRP1-UP
Group No: 243-5157 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8N5991 | 2 HOSE | 2 | |
| 9N0720 | 3 ELBOW-AIR INLET | 4 | |
| 1230275 | 4 CONNECTOR-FILTER | 1 | |
| 1505030 | 5 INDICATOR-AIR FILTER CHANGE | 1 | |
| 2051627 | 6 BRACKET | 1 | |
| 2522230 | 7 TUBE | 1 | |
| 2522231 | 8 TUBE | 1 | |
| 2539105 | 9 BRACKET AS | 1 | |
| 2543566 | 10 AIR CLEANER GP | 2 | |
| 2544293 | 11 CAP GP-AIR CLEANER | 2 | |
| 5P0600 | 11A CLAMP-HOSE | 1 | |
| 2545719 | 12 MANIFOLD AS | 1 | |
| 2545723 | 13 BRACKET | 1 | |
| 2545724 | 14 BRACKET | 1 | |
| 2559392 | 15 PIPE-EXTENSION | 2 | |
| 0966166 | 16 WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 1B3581 | 17 CLIP | 3 | |
| 2162212 | 18 CLAMP | 8 | |
| 2338484 | 19 CLAMP (BOLT SPRING) | 4 | |
| 8T0285 | 20 SCREW-MACHINE (M4X0.7X12-MM) | 2 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 12 | |
| 8T4136 | 22 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4139 | 23 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4779 | 25 BOLT (M16X2X35-MM) | 6 | |
| 9X8257 | 26 WASHER (17.5X30X3.5-MM THK) | 6 | |
| 3B6487 | 27 COUPLING (PIPE) | 1 | |
| 6V1363 | 28 HOSE (1.4-M) |
