System And Components
252-8439 CYLINDER HEAD GPS/N THY1-UP
Group No: 252-8439
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W2715 | 1 LOCK-RETAINER | 24 | |
| 2A4429 | 2 LOCK-RETAINER | 24 | |
| 2604856 | 3 GUIDE-VALVE | 12 | |
| 1632478 | 4 SEAL-VALVE STEM | 12 | |
| 1833407 | 5 PLUG AS | 6 | |
| 9S8004 | PLUG (9/16-18-THD) | 1 | |
| 1534906 | SEAL-O-RING | 1 | |
| 2717442 | 6 PLUG | 2 | |
| 1832317 | 7 SEAL-O-RING | 2 | |
| 1906115 | 8 SPRING-VALVE (INNER) | 12 | |
| 1906117 | 9 SPRING-VALVE (OUTER) | 12 | |
| 2112134 | 10 RETAINER | 12 | |
| 2170609 | 11 SEAT-VALVE SPRING | 6 | |
| 2418382 | 12 VALVE-INLET | 12 | |
| 2418383 | 13 VALVE-EXHAUST | 12 | |
| 2418384 | 14 RETAINER | 12 | |
| 2418386 | 15 SPRING-VALVE (INNER) | 12 | |
| 2418385 | 16 SPRING-VALVE (OUTER) | 12 | |
| 2418387 | 17 SEAT | 6 | |
| 2595829 | 18 GUIDE-VALVE | 12 | |
| 2418390 | 19 SEAL-VALVE STEM | 12 | |
| 2528438 | 20 CYLINDER HEAD AS | 1 | |
| 1488395 | 21 PLUG AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S8005 | PLUG (3/4-16-THD) | 1 | |
| 8T6764 | 22 PLUG-PIPE (1/8-27-THD) | 2 |
