System And Components
273-5614 LINES GP-OIL SUPPLYS/N LDX1-UP
Group No: 273-5614
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1L5081 | 1 SPACER (0.41X0.75X0.56-IN THK) | 1 | |
| 1488316 | 2 CONNECTOR AS | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1488378 | 3 ELBOW AS | 1 | |
| 6V8724 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488435 | 4 TEE AS | 1 | |
| 6V8781 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 2873573 | 5 HOSE AS | 1 | |
| 1920729 | 6 MANIFOLD GP-CONTROL (DEMAND FAN) | 1 | |
| 2254991 | 7 BRACKET AS | 1 | |
| 8T5413 | STUD-WELD (M10X1.5X25-MM) | 1 | |
| 2575545 | 8 TUBE AS | 1 | |
| 2860658 | 9 HOSE AS | 1 | |
| 2598867 | 10 HOSE AS | 1 | |
| 2598868 | 11 HOSE AS | 1 | |
| 2798782 | 12 BRACKET AS | 1 | |
| 8T4133 | NUT (M10X1.5-THD) | 2 | |
| 0672551 | 13 CLIP | 1 | |
| 1488318 | 14 CONNECTOR AS | 2 | |
| 6V8634 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488336 | 15 CONNECTOR AS | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1488340 | 16 CONNECTOR AS | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488354 | 17 ELBOW AS | 1 | |
| 6V9002 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488368 | 18 ELBOW AS | 1 | |
| 6V8627 | ELBOW | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 5P4116 | 19 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 6V5049 | 20 SEAL-O-RING | 1 | |
| 7W7381 | 21 FITTING-OUTLET | 1 | |
| 8M2773 | 22 CLIP (LOOP) | 2 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 9 | |
| 8T4133 | 24 NUT (M10X1.5-THD) | 2 | |
| 8T4186 | 25 BOLT (M10X1.5X40-MM) | 1 | |
| 8T4189 | 26 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4195 | 27 BOLT (M10X1.5X30-MM) | 3 | |
| 8T6466 | 28 BOLT (M10X1.5X60-MM) | 2 |
