System And Components
259-2303 LINES GP-TURBOCHARGER AIR -ATAACS/N LDX1-UP
Group No: 259-2303
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1770581 | 1 HOSE | 3 | |
| 1939879 | 2 TUBE | 1 | |
| 1974581 | 3 BRACKET AS | 1 | |
| 1707491 | STUD-WELD (M10X1.5X35-MM) | 2 | |
| 2027935 | 4 HOSE | 1 | |
| 2180607 | 5 TUBE | 1 | |
| 2180608 | 6 HOSE | 1 | |
| 2566341 | 7 TUBE | 1 | |
| 2566342 | 8 BRACKET AS | 1 | |
| 1440367 | 9 CLAMP-HOSE | 20 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 5 | |
| 8T4133 | 11 NUT (M10X1.5-THD) | 3 | |
| 8T4139 | 12 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4179 | 13 BOLT (M12X1.75X20-MM) | 1 | |
| 8T4195 | 14 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4223 | 15 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 9X2646 | 16 CLIP (SLOT) | 3 | |
| 9X2647 | 17 CLIP (TAB) | 3 |
