System And Components
264-1958 LINES GP-ENGINE OILS/N TXG3074-UP; LHX14535-UP
Group No: 264-1958
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2P3760 | 1 GASKET | 1 | |
| 4N0826 | 2 ELBOW | 1 | |
| 4N1216 | 3 TUBE-COOLER BYPASS (ENGINE OIL) | 1 | |
| 4N8150 | 4 SPRING | 1 | |
| 3929208 | 5 PLUNGER-VALVE (RELIEF) | 1 | |
| 1632916 | 6 TUBE AS | 1 | |
| 1632917 | 7 TUBE AS | 1 | |
| 2235814 | 8 BODY-COOLER BYPASS (ENGINE OIL) | 1 | |
| 2641957 | 9 BRACKET AS | 1 | |
| 0S1571 | 10 BOLT (3/8-16X1.75-IN) | 1 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1590 | 12 BOLT (3/8-16X2-IN) | 1 | |
| 0S1594 | 13 BOLT (3/8-16X1-IN) | 11 | |
| 5P5846 | 14 SEAL-O-RING | 1 | |
| 5P8068 | 15 SEAL-O-RING | 2 | |
| 3717186 | 16 PLUG AS | 2 | |
| 2147567 | 16A SEAL-O-RING | 1 | |
| 3603678 | 16B PLUG-O-RING | 1 | |
| 1A2029 | 17 BOLT (3/8-16X1.125-IN) | 4 | |
| 2N3350 | 18 SEAL-O-RING | 2 | |
| 2P3761 | 19 COVER | 1 | |
| 1135304 | 20 SEAL-O-RING | 3 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 | |
| 8C5230 | 22 SEAL-O-RING | 1 |
