System And Components
222-0801 LINES GP-AIRS/N 2GB1-UP; 45P1-UP; 46P1-UP
Group No: 222-0801
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1862002 | 1 HOSE | 1 | |
| 1094203 | 2 ELBOW | 1 | |
| 1270929 | 3 CLAMP-V BAND | 1 | |
| 1296400 | 4 ADAPTER | 1 | |
| 2280507 | 5 TUBE | 1 | |
| 2368247 | 6 TUBE | 1 | |
| 2368248 | 7 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2453572 | 8 HOSE | 1 | |
| 0S1588 | 9 BOLT (3/8-16X1.25-IN) | 4 | |
| 1013125 | 10 GASKET (AIR INLET MANIFOLD) | 1 | |
| 2087448 | 11 CLAMP | 8 | |
| 2B4229 | 13 CLAMP-AIR CLEANER | 1 | |
| 4L9337 | 14 BOLT (3/8-16X1.5-IN) | 1 | |
| 5M3062 | 15 BOLT (3/8-16X0.75-IN) | 2 | |
| 6E6549 | 16 WASHER (11X27X6-MM THK) | 1 | |
| 7E8630 | 17 HOSE-AIR INLET | 2 | |
| 8C3089 | 18 SEAL-O-RING | 1 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 7 |
