System And Components
7E-4697 CYLINDER BLOCK GPS/N 41Z1-8064
Group No: 7E-4697
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E3632 | 1 JET AS-PISTON COOLING | 6 | |
| 8T6757 | 2 PLUG-PIPE | 3 | |
| 7W6534 | 3 PLUG-PIPE | 1 | |
| 1083913 | 4 CYLINDER BLOCK AS | 1 | |
| 9L5854 | 4A BAND-FILLER (130.2-MM ID) | 6 | |
| 1102220 | 4B SEAL-LINER | 6 | |
| 1427072 | 4C SEAL-LINER | 6 | |
| 1426217 | 4D SEAL-O-RING | 6 | |
| 3P1323 | 4E BOLT-BEARING CAP (7/8-14X7.75-IN) | 14 | |
| 9H1031 | 4F WASHER-HARD (24X41.5X6-MM THK) | 14 | |
| 1979322 | 4G LINER-CYLINDER BLOCK | 6 | |
| 4N5857 | 4H CAP-CRANKSHAFT BEARING | 7 | |
| 8T6763 | 5 PLUG-PIPE (1/4-18-THD) | 3 | |
| 1S9540 | 6 DOWEL | 2 | |
| 3S5496 | 7 SEAL-O-RING | 2 | |
| 7W6492 | 8 PLUG-PIPE (1/2-14-THD) | 1 | |
| 1195155 | 9 SEAL-O-RING | 1 | |
| 0307571 | 10 BOLT (3/8-16X1-IN) | 4 | |
| 4W8585 | 11 COVER | 1 | |
| 7W6081 | 12 GASKET | 1 | |
| 4N0683 | 13 DOWEL | 4 | |
| 4N1650 | 14 DOWEL | 2 | |
| 6I2981 | 15 PLATE-BLOCK | 1 | |
| 6I4024 | 16 GASKET-PLATE | 1 | |
| 8S9094 | 17 PLUG-ORIFICE | 1 | |
| 9S4190 | 18 PLUG-O-RING (7/8-14-THD) | 2 | |
| 1144427 | 19 SEAL-O-RING | 2 | |
| 7X7732 | 20 PLUG-PIPE | 6 | |
| 7E6479 | 21 BOLT-SPECIAL (OIL JET) | 6 | |
| 4N0685 | 22 BUSHING (1-IN WIDE) | 6 | |
| 4N6658 | 23 BUSHING (1.3-IN WIDE) | 1 | |
| 8T6764 | 24 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9S8009 | 25 PLUG-O-RING | 1 | |
| 1007399 | 26 PLUG | 2 | |
| 3E6747 | 27 SEAL-O-RING | 2 | |
| 9S4182 | 28 PLUG (7/16-20-THD) | 1 | |
| 9X7378 | 29 SEAL-O-RING | 1 | |
| 1010523 | INSERT-LINER SEAT (5.21-MM THK)(0.05MM US) | 6 |
