System And Components
261-0669 DRIVE GP-FANS/N BNT2500-10110
Group No: 261-0669
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4564 | 1 WASHER-RETAINING (17X54X25-MM THK) | 1 | |
| 2W6280 | 2 BRACKET AS-FAN | 1 | |
| 8N8980 | SHAFT-FAN | 1 | |
| 3B8485 | 3 ELBOW (FAN DRIVE) | 1 | |
| 6N6655 | 4 V-BELT SET (INCLUDES 3-BELTS)(FAN DRIVE) | 1 | |
| 8N8978 | 5 SPACER (40X53.98X20-MM THK) | 1 | |
| 8N8979 | 6 SPACER (42X54X90-MM THK) | 1 | |
| 8N8983 | 7 HUB-FAN PULLEY | 1 | |
| 8N9394 | 8 HOSE AS | 1 | |
| 1569688 | 9 SUPPORT-COMPRESSOR | 1 | |
| 1642556 | 10 BRACKET AS | 1 | |
| 1881034 | 11 ADAPTER | 1 | |
| 1908455 | 12 PULLEY-FAN (3-GROOVE, 1-GROOVE) | 1 | |
| 5F0149 | 13 SEAL-O-RING | 1 | |
| 5P9297 | 14 CLIP (LOOP) | 1 | |
| 5S7382 | 15 BOLT (3/8-16X1.375-IN) | 6 | |
| 6H3956 | 16 PIN | 1 | |
| 6H3957 | 17 BALL BEARING | 2 | |
| 6V8188 | 18 NUT (1/2-13-THD) | 2 | |
| 7X0297 | 19 BOLT (3/8-16X5.75-IN) | 1 | |
| 7X7890 | 20 BOLT (5/8-11X9.5-IN) | 1 | |
| 8B8255 | 21 SEAL-LIP TYPE | 1 | |
| 8T2501 | 22 BOLT (3/8-16X2-IN) | 2 | |
| 8T2502 | 23 BOLT (3/8-16X1.125-IN) | 6 | |
| 8T4835 | 24 BOLT (1/2-13X2-IN) | 8 | |
| 8T4896 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 1P0808 | GREASE-MULTIPURPOSE |
