System And Components
317-7596 HOUSING GP-FLYWHEELS/N 2GR1-8284
Group No: 317-7596
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4B8407 | 1 GASKET-COPPER | 1 | |
| 1044767 | 2 ADAPTER | 1 | |
| 0S1595 | 3 BOLT (1/2-13X1.25-IN) | 1 | |
| 1D4574 | 4 BOLT (1/2-13X6-IN) | 7 | |
| 1D4597 | 5 BOLT (5/8-11X6.5-IN) | 1 | |
| 3177597 | 6 HOUSING AS-FLYWHEEL | 1 | |
| 3F6795 | DOWEL | 3 | |
| 3F6808 | DOWEL | 1 | |
| 7N2047 | DOWEL | 3 | |
| 3K0360 | 7 SEAL-O-RING | 1 | |
| 5D9514 | 8 BOLT (5/8-11X6.25-IN) | 11 | |
| 5P4626 | 9 BOLT (5/8-11X10.5-IN) | 2 | |
| 5P8245 | 10 WASHER-HARD (13.5X25.5X3-MM THK) | 14 | |
| 5P8247 | 11 WASHER-HARD (17X32X3.5-MM THK) | 12 | |
| 8T6763 | 12 PLUG-PIPE (1/4-18-THD) | 5 | |
| 8T6765 | 13 PLUG-PIPE (1/4-18-THD) | 1 | |
| 9S4185 | 14 PLUG (3/4-16-THD) | 1 | |
| 9X8873 | 15 BOLT (1/2-13X2.25-IN) | 8 | |
| 8T4122 | 16 WASHER-HARD (17X32X3.5-MM THK) | 2 |
