System And Components
4W-6170 LINES GP-ENGINE OILS/N 2GR1-UP
Group No: 4W-6170
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W5596 | 1 COVER | 1 | |
| 5P4892 | SEAL-O-RING | 1 | |
| 0S1591 | 2 BOLT (3/8-16X1.5-IN) | 2 | |
| 7N5416 | 3 ELBOW (OUTLET) | 1 | |
| 0S1594 | 4 BOLT (3/8-16X1-IN) | 12 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 7W7280 | 6 ADAPTER-SUPPLY | 1 | |
| 0619456 | 7 SEAL-O-RING | 4 | |
| 0L1143 | 8 BOLT (3/8-16X2.5-IN) | 4 | |
| 9S4190 | 9 PLUG-O-RING (7/8-14-THD) | 1 | |
| 6V4589 | SEAL-O-RING | 1 | |
| 6B5072 | 10 ADAPTER | 1 | |
| 2W1055 | 11 ELBOW | 1 | |
| 5P7817 | 12 SEAL-O-RING | 1 | |
| 1A5964 | 13 BOLT (3/8-16X4.5-IN) | 4 | |
| 3B7764 | 14 BUSHING (REDUCING) | 1 | |
| 9S4182 | 15 PLUG (7/16-20-THD) | 2 | |
| 6V5048 | 16 SEAL-O-RING | 2 | |
| 2W1053 | 17 PLUG | 1 | |
| 2W1969 | 18 VALVE-BYPASS (OIL COOLER) | 1 | |
| 2W1635 | 19 SPRING | 1 | |
| 8N1991 | 20 RING-RETAINING | 2 | |
| 8N1992 | 21 RETAINER | 4 | |
| 6V3908 | 22 SEAL-O-RING | 1 | |
| 3P0655 | 23 SEAL-O-RING | 1 | |
| 3P0649 | 24 SEAL-O-RING | 2 | |
| 1W2447 | 25 ADAPTER-OUTLET | 1 | |
| 4W5570 | 26 ELBOW | 1 | |
| 5F4899 | 27 BOLT (3/8-16X5.5-IN) | 1 | |
| 6B9202 | 28 SPRING | 2 | |
| 7N7697 | 29 PLUNGER AS | 2 | |
| 0S1588 | 30 BOLT (3/8-16X1.25-IN) | 2 | |
| 8N2929 | 31 COVER | 2 | |
| 0S1594 | 1 BOLT (3/8-16X1-IN) | 8 | |
| 7N5413 | 2 ELBOW | 1 | |
| 3P0655 | 3 SEAL-O-RING | 2 | |
| 8T6765 | 4 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5M2894 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 6V0267 | 6 CLIP (TAB) | 1 | |
| 0S1591 | 7 BOLT (3/8-16X1.5-IN) | 1 | |
| 4B3140 | 8 COVER | 1 | |
| 6V0268 | 9 CLIP (SLOT) | 1 | |
| 8N1992 | 10 RETAINER | 2 | |
| 3P0649 | 11 SEAL-O-RING | 2 | |
| 5P5846 | 12 SEAL-O-RING | 1 | |
| 4W5890 | 13 PLUG | 1 | |
| 1N3333 | 14 TUBE | 1 | |
| 0S1588 | 15 BOLT (3/8-16X1.25-IN) | 4 | |
| 2W1554 | 16 TUBE | 1 | |
| 8M9024 | 17 WASHER-HARD (10.2X22.5X5-MM THK) | 1 | |
| 8G3659 | 18 PLATE | 1 |
