4W-6170 LINES GP-ENGINE OILS/N 2GR1-UP

Group No: 4W-6170

Part Number	Part Name	Qty
4W5596	1 COVER	1
5P4892	SEAL-O-RING	1
0S1591	2 BOLT (3/8-16X1.5-IN)	2
7N5416	3 ELBOW (OUTLET)	1
0S1594	4 BOLT (3/8-16X1-IN)	11
5M2894	5 WASHER-HARD (10.2X18.5X2.5-MM THK)	10
2W7226	6 ADAPTER	1
0619456	7 SEAL-O-RING	4
0L1143	8 BOLT (3/8-16X2.5-IN)	4
3P0764	9 PLUG	1
6B5072	10 ADAPTER	1
2W1055	11 ELBOW	1
5P7817	12 SEAL-O-RING	1
1A5964	13 BOLT (3/8-16X4.5-IN)	4
8T6762	14 PLUG-PIPE (1/2-14-THD)	1
9S4182	15 PLUG (7/16-20-THD)	2
6V5048	16 SEAL-O-RING	2
2W1053	17 PLUG	1
2W1969	18 VALVE-BYPASS (OIL COOLER)(OIL COOLER)	1
2W1635	19 SPRING	1
8N1991	20 RING-RETAINING	1
8N1992	21 RETAINER	2
6V3908	22 SEAL-O-RING	1
3P0655	23 SEAL-O-RING	1
1092332	24 SEAL-O-RING	3
1W2447	25 ADAPTER-OUTLET	1
7C9217	26 ELBOW (OIL COOLER BYPASS)	1
5F4899	27 BOLT (3/8-16X5.5-IN)	1
6B9202	28 SPRING	2
7N7697	29 PLUNGER AS	2
7M1808	DOWEL	1
0S1588	30 BOLT (3/8-16X1.25-IN)	2
8N2929	31 COVER	2
6V4589	32 SEAL-O-RING	2
9S4190	33 PLUG-O-RING (7/8-14-THD)	1
0S1594	34 BOLT (3/8-16X1-IN)	1
1113820	35 RING-RETAINING	1
9S8752	36 NUT-FULL (3/8-16-THD)	2
1008075	37 CLAMP AS	2
0S1571	38 BOLT (3/8-16X1.75-IN)	2
0S1594	39 BOLT (3/8-16X1-IN)	8
7N5413	40 ELBOW	1
3P0655	41 SEAL-O-RING	2
8T6765	42 PLUG-PIPE (1/4-18-THD)	1
5M2894	43 WASHER-HARD (10.2X18.5X2.5-MM THK)	4
6V0267	44 CLIP (TAB)	1
0S1591	45 BOLT (3/8-16X1.5-IN)	1
4B3140	46 COVER	1
6V0268	47 CLIP (SLOT)	1
8N1992	48 RETAINER	2
3P0649	49 SEAL-O-RING	2
5P5846	50 SEAL-O-RING	1
4W5890	51 PLUG	1
1N3333	52 TUBE	1
0S1588	53 BOLT (3/8-16X1.25-IN)	4
2W1554	54 TUBE	1
8M9024	55 WASHER-HARD (10.2X22.5X5-MM THK)	1
8G3659	56 PLATE	1
