4W-6170 LINES GP-ENGINE OILS/N 2GR1-8278

Group No: 4W-6170

Part Number	Part Name	Qty
1N3333	1 TUBE	1
1W2447	2 ADAPTER-OUTLET	1
2W1053	3 PLUG	1
2W1055	4 ELBOW	1
2W1635	5 SPRING	1
2W1969	6 VALVE-BYPASS (OIL COOLER)(OIL COOLER)	1
2W7226	7 ADAPTER	1
3P0764	8 PLUG	1
4B3140	9 COVER	1
4W5596	10 COVER	1
4W5890	11 PLUG	1
6B0933	12 SPACER (10.31X19.05X6.35-MM THK)	4
6B9202	13 SPRING	2
7C9217	14 ELBOW (OIL COOLER BYPASS)	1
7N5413	15 ELBOW	1
7N5416	16 ELBOW (OUTLET)	1
7N7697	17 PLUNGER AS	2
7M1808	DOWEL	1
8N1991	18 RING-RETAINING	1
8N1992	19 RETAINER	4
8N2929	20 COVER	2
9M4594	21 SPACER (0.406X0.875X0.75-IN THK)	1
1008075	22 CLAMP AS	1
1030897	23 TUBE	1
1113820	24 RING-RETAINING	1
2640450	25 CLAMP AS	1
9S8752	NUT-FULL (3/8-16-THD)	2
0619456	26 SEAL-O-RING	4
0L1143	27 BOLT (3/8-16X2.5-IN)	4
0S1571	28 BOLT (3/8-16X1.75-IN)	3
0S1588	29 BOLT (3/8-16X1.25-IN)	10
0S1591	30 BOLT (3/8-16X1.5-IN)	2
0S1594	31 BOLT (3/8-16X1-IN)	16
1092332	32 SEAL-O-RING	5
1A5964	33 BOLT (3/8-16X4.5-IN)	4
3P0655	34 SEAL-O-RING	3
5F4899	35 BOLT (3/8-16X5.5-IN)	1
5M2894	36 WASHER-HARD (10.2X18.5X2.5-MM THK)	13
5P4892	37 SEAL-O-RING	1
5P5846	38 SEAL-O-RING	1
5P7817	39 SEAL-O-RING	1
6B5072	40 ADAPTER	1
6V1572	41 CLIP (SLOT)	1
6V1573	42 CLIP (TAB)	1
6V1574	43 GROMMET	1
6V3908	44 SEAL-O-RING	1
6V4589	45 SEAL-O-RING	2
6V5048	46 SEAL-O-RING	2
8T6762	47 PLUG-PIPE (1/2-14-THD)	1
8T6765	48 PLUG-PIPE (1/4-18-THD)	1
9S4182	49 PLUG (7/16-20-THD)	2
9S4190	50 PLUG-O-RING (7/8-14-THD)	1
8T6765	51 PLUG-PIPE (1/4-18-THD)	2
8T6765	52 PLUG-PIPE (1/4-18-THD)	1
