System And Components
155-0542 LINES GP-TURBOCHARGER WATERS/N 2GR1-UP
Group No: 155-0542
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6458 | 1 WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 4P0707 | 2 CLAMP AS | 2 | |
| 3078373 | GROMMET | 1 | |
| 4W5463 | 3 BRACKET | 2 | |
| 7F2050 | 4 LOCKNUT (3/4-16-THD) | 2 | |
| 3419211 | 5 GASKET | 8 | |
| 7N7878 | 6 PLATE-COVER | 4 | |
| 1070744 | 7 BLOCK | 2 | |
| 8T1885 | 8 CLIP (SLOT) | 2 | |
| 8T1886 | 9 CLIP (TAB) | 2 | |
| 1126053 | 10 TUBE AS | 1 | |
| 1126054 | 11 TUBE AS | 1 | |
| 1138188 | 12 ELBOW | 2 | |
| 1274470 | 13 BRACKET | 1 | |
| 1526594 | 14 BRACKET | 2 | |
| 1550499 | 15 TUBE AS | 1 | |
| 3991909 | 16 TUBE AS-WATER | 2 | |
| 1184728 | 17 ELBOW | 2 | |
| 0L1143 | 18 BOLT (3/8-16X2.5-IN) | 1 | |
| 0S1594 | 19 BOLT (3/8-16X1-IN) | 2 | |
| 0S1608 | 20 BOLT (3/8-16X3.75-IN) | 2 | |
| 0S1617 | 21 BOLT (5/16-18X0.75-IN) | 2 | |
| 2P2204 | 22 ELBOW-UNION | 1 | |
| 2P8130 | 23 TEE-UNION (BULKHEAD) | 1 | |
| 3B1915 | 24 BOLT (3/8-16X1.375-IN) | 6 | |
| 3E4352 | 25 WASHER-HARD (8.8X20.5X2.5-MM THK) | 2 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 17 | |
| 6V6609 | 28 SEAL-O-RING | 6 | |
| 8M0505 | 29 ADAPTER | 4 | |
| 9S8752 | 31 NUT-FULL (3/8-16-THD) | 1 | |
| 2A4639 | 32 BOLT (3/8-16X1.625-IN) | 8 | |
| 2721777 | 33 WASHER-HARD (11X18.5X15-MM THK) | 8 |
