Assembly
100%

123-6921 LINES GP-AIRS/N 2GR1-1419

Group No: 123-6921
Part NumberPart NameQty
6V51011 SEAL-O-RING8
8T67622 PLUG-PIPE (1/2-14-THD)6
9F27733 BOLT (3/8-16X8.5-IN)6
1S11504 SPACER (0.391X0.5X0.19-IN THK)12
2N27655 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)8
2N27666 LOCKNUT (3/8-16-THD)20
4I31447 WASHER-HARD (10.2X22X3.2-MM THK)4
4W02268 ADAPTER2
7C79099 ELBOW (AIR INLET)6
7C791010 ELBOW (AIR INLET)2
7C819911 FLANGE8
7L319512 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)12
7N508013 GASKET-MANIFOLD8
7N508714 GASKET2
107076515 ADAPTER2
107674716 MANIFOLD (AIR INLET)1
110951717 COVER1
111207618 ELBOW1
112359119 COVER1
123698220 BAR2
123698321 PLATE1
127811222 SUPPORT-EXHAUST PIPE (LH)1
127811323 SUPPORT-EXHAUST PIPE (RH)1
0S050924 BOLT (3/8-16X0.75-IN)6
0S158825 BOLT (3/8-16X1.25-IN)2
0S159026 BOLT (3/8-16X2-IN)4
0S159127 BOLT (3/8-16X1.5-IN)16
0S159428 BOLT (3/8-16X1-IN)12
109741129 SEAL-O-RING2
1T072030 BOLT-12 POINT HEAD (3/8-16X1.25-IN)32
2A463931 BOLT (3/8-16X1.625-IN)16
4S589832 SEAL-O-RING8
5M289433 WASHER-HARD (10.2X18.5X2.5-MM THK)72
5P894034 SEAL-O-RING1
6V097335 SEAL-O-RING2
6V391736 SEAL-O-RING4
