System And Components
123-6921 LINES GP-AIRS/N 2GR1420-UP
Group No: 123-6921
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9X6458 | 1 WASHER-HARD (10.2X22.5X3-MM THK) | 4 | |
| 1S1150 | 4 SPACER (0.391X0.5X0.19-IN THK) | 12 | |
| 2N2765 | 5 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 8 | |
| 4W0226 | 6 ADAPTER | 2 | |
| 7C7909 | 7 ELBOW (AIR INLET) | 6 | |
| 7C7910 | 8 ELBOW (AIR INLET) | 2 | |
| 7C8199 | 9 FLANGE | 8 | |
| 7N5080 | 10 GASKET-MANIFOLD | 8 | |
| 7N5087 | 11 GASKET | 2 | |
| 7W3145 | 12 PLATE | 4 | |
| 2839598 | 13 MANIFOLD (AIR INLET) | 1 | |
| 1109517 | 14 COVER | 1 | |
| 1123591 | 15 COVER | 1 | |
| 1236982 | 16 BAR | 2 | |
| 1236983 | 17 PLATE | 1 | |
| 1278112 | 18 SUPPORT-EXHAUST PIPE (LH) | 1 | |
| 1278113 | 19 SUPPORT-EXHAUST PIPE (RH) | 1 | |
| 1467383 | 20 FLANGE | 2 | |
| 1550540 | 21 ELBOW | 1 | |
| 1550541 | 22 ELBOW | 1 | |
| 1550544 | 23 ELBOW | 1 | |
| 1550545 | 24 ELBOW | 1 | |
| 1566261 | 25 BRACKET | 2 | |
| 1687800 | 26 LOCKNUT (3/8-16-THD) | 20 | |
| 0S0509 | 27 BOLT (3/8-16X0.75-IN) | 6 | |
| 0S1590 | 28 BOLT (3/8-16X2-IN) | 4 | |
| 0S1591 | 29 BOLT (3/8-16X1.5-IN) | 18 | |
| 0S1594 | 30 BOLT (3/8-16X1-IN) | 6 | |
| 0S1619 | 31 BOLT (3/8-16X3-IN) | 2 | |
| 0T0573 | 32 BOLT (3/8-16X2.75-IN) | 2 | |
| 1097411 | 33 SEAL-O-RING | 2 | |
| 1A2029 | 34 BOLT (3/8-16X1.125-IN) | 8 | |
| 1T0720 | 35 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 32 | |
| 2A4639 | 36 BOLT (3/8-16X1.625-IN) | 16 | |
| 4S5898 | 37 SEAL-O-RING | 8 | |
| 5D5957 | 38 SEAL-O-RING | 2 | |
| 5M2894 | 39 WASHER-HARD (10.2X18.5X2.5-MM THK) | 84 | |
| 5P8940 | 40 SEAL-O-RING | 1 | |
| 6V3917 | 41 SEAL-O-RING | 8 | |
| 6V5101 | 42 SEAL-O-RING | 8 | |
| 7L3195 | 43 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 12 | |
| 8T6762 | 44 PLUG-PIPE (1/2-14-THD) | 6 | |
| 8T6764 | 45 PLUG-PIPE (1/8-27-THD) | 2 | |
| 9F2773 | 46 BOLT (3/8-16X8.5-IN) | 6 |
