System And Components
220-3697 DRIVE GP-FANS/N 1AB565-749; 1FB317-350; 1JB417-556
Group No: 220-3697
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4564 | 1 WASHER-RETAINING (17X54X25-MM THK) | 1 | |
| 2W6280 | 2 BRACKET AS-FAN | 1 | |
| 8N8980 | SHAFT-FAN | 1 | |
| 8N8978 | 3 SPACER (40X53.98X20-MM THK) | 1 | |
| 8N8979 | 4 SPACER (42X54X90-MM THK) | 1 | |
| 8N8983 | 5 HUB-FAN PULLEY | 1 | |
| 3485434 | 6 IDLER AS | 1 | |
| 2302186 | 7 SUPPORT | 1 | |
| 2481475 | 8 ADAPTER | 1 | |
| 2950494 | 9 PULLEY-FAN | 1 | |
| 3812510 | 10 BELT TENSIONER | 1 | |
| 3215168 | 11 BELT-SERPENTINE | 1 | |
| 5F0149 | 12 SEAL-O-RING | 1 | |
| 5M6214 | 13 PLUG (1/8-27 PTF) | 1 | |
| 6H3956 | 14 PIN | 1 | |
| 6H3957 | 15 BALL BEARING | 2 | |
| 6V8188 | 16 NUT (1/2-13-THD) | 1 | |
| 7X0288 | 17 BOLT (3/8-16X1.625-IN) | 6 | |
| 7X7890 | 18 BOLT (5/8-11X9.5-IN) | 1 | |
| 8B7997 | 19 BOLT-SOCKET HEAD (1/2-13X2-IN) | 2 | |
| 8B8255 | 20 SEAL-LIP TYPE | 1 | |
| 8T4121 | 21 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4178 | 22 BOLT (M10X1.5X90-MM) | 1 | |
| 8T4195 | 23 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4223 | 24 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4835 | 25 BOLT (1/2-13X2-IN) | 4 | |
| 9B7237 | 26 BOLT (3/8-16X1.25-IN) | 6 | |
| 2432310 | 27 COVER | 1 |
