System And Components
221-8590 MUFFLER GPS/N 90Z1-UP; 91Z1-UP
Group No: 221-8590
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2N2765 | 1 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 2 | |
| 5L8854 | 2 RING-SEALING | 2 | |
| 9L5839 | 3 COUPLING-EXHAUST | 1 | |
| 9N1941 | 4 CLAMP-V BAND | 1 | |
| 2315174 | 5 SUPPORT-EXHAUST | 1 | |
| 2525161 | 6 SUPPORT AS | 1 | |
| 4D6293 | BOSS (3/8-16X1.31-IN) | 6 | |
| 2587647 | 7 PLATE | 1 | |
| 2858657 | 8 MUFFLER AS | 1 | |
| 2858658 | 9 PIPE GP-EXHAUST | 1 | |
| 1B5355 | 10 NUT-FULL (3/8-16-THD) | 1 | |
| 2N2766 | 11 LOCKNUT (3/8-16-THD) | 2 | |
| 4L9337 | 12 BOLT (3/8-16X1.5-IN) | 2 | |
| 5P1075 | 13 WASHER-HARD (10.2X22.5X3-MM THK) | 6 | |
| 6V8801 | 14 NUT (3/8-16-THD) | 2 | |
| 7P4595 | 15 CLAMP | 1 | |
| 8T2502 | 16 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4132 | 17 NUT (M16X2-THD) | 2 | |
| 8T4140 | 18 BOLT (M16X2X60-MM) | 2 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 8T9377 | 20 BOLT (3/8-16X2.25-IN) | 1 | |
| 9B7237 | 21 BOLT (3/8-16X1.25-IN) | 2 | |
| 9X8257 | 22 WASHER (17.5X30X3.5-MM THK) | 4 |
