System And Components
221-8590 MUFFLER GPS/N 90Z1-UP; 91Z1-UP
Group No: 221-8590
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5L8854 | 1 RING-SEALING | 2 | |
| 9L5839 | 2 COUPLING-EXHAUST | 1 | |
| 2315174 | 3 SUPPORT-EXHAUST | 1 | |
| 2525161 | 4 SUPPORT AS | 1 | |
| 4D6293 | BOSS (3/8-16X1.31-IN) | 6 | |
| 3307215 | 5 EJECTOR AS-EXHAUST | 1 | |
| 2911558 | 6 BRACE | 1 | |
| 4701289 | 7 MUFFLER AS | 1 | |
| 3314954 | 8 CLAMP | 2 | |
| 1984777 | 9 WASHER-HARD (11X25X10-MM THK) | 4 | |
| 1984780 | 10 WASHER-HARD (17.5X32X8-MM THK) | 4 | |
| 2N2765 | 11 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN) | 2 | |
| 2N2766 | 12 LOCKNUT (3/8-16-THD) | 2 | |
| 5S7382 | 13 BOLT (3/8-16X1.375-IN) | 9 | |
| 2372228 | 14 BOLT (M10X1.5X70-MM) | 2 | |
| 7X2554 | 15 BOLT (M16X2X70-MM) | 2 | |
| 8T4121 | 16 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 9M6527 | 17 WASHER-HARD (10.2X25.5X5-MM THK) | 6 | |
| 9N1941 | 18 CLAMP-V BAND | 1 | |
| 8T4132 | 19 NUT (M16X2-THD) | 2 | |
| 6V8801 | 20 NUT (3/8-16-THD) | 3 | |
| 8T4133 | 21 NUT (M10X1.5-THD) | 2 |
