System And Components
271-9380 LINES GP-AIR COMPRESSORS/N 5XD4474-UP
Group No: 271-9380
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3R2705 | 1 UNION-FLARED | 1 | |
| 4W1117 | 2 ADAPTER | 1 | |
| 8M7065 | 3 GASKET (AIR INLET) | 1 | |
| 0340912 | 4 TUBE | 1 | |
| 1765647 | 5 PLATE | 1 | |
| 1765648 | 6 TUBE AS | 1 | |
| 2719402 | 7 TUBE AS | 1 | |
| 2719403 | 8 TUBE AS | 1 | |
| 2719404 | 9 TUBE AS | 1 | |
| 2719409 | 10 TUBE AS | 1 | |
| 0307949 | 11 ELBOW | 1 | |
| 0307950 | 12 ELBOW | 1 | |
| 0321269 | 13 ELBOW | 1 | |
| 0L2070 | 14 BOLT (3/8-16X2.25-IN) | 1 | |
| 0S0509 | 15 BOLT (3/8-16X0.75-IN) | 1 | |
| 0S1591 | 16 BOLT (3/8-16X1.5-IN) | 1 | |
| 0S1617 | 17 BOLT (5/16-18X0.75-IN) | 2 | |
| 1144427 | 18 SEAL-O-RING | 1 | |
| 2N1287 | 19 ELBOW-FLARED | 1 | |
| 3D2824 | 20 SEAL-O-RING | 1 | |
| 3L2875 | 21 CLIP | 1 | |
| 3R5387 | 22 CONNECTOR | 2 | |
| 4B0418 | 23 CLIP (LOOP) | 1 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 7C0307 | 25 GASKET | 1 | |
| 8M0755 | 26 ADAPTER | 1 | |
| 8T6764 | 27 PLUG-PIPE (1/8-27-THD) | 1 | |
| 9L5125 | 28 ELBOW | 1 | |
| 9X6458 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 1 |
