System And Components
134-3910 LINES GP-TURBOCHARGER OILS/N 5XD4018-UP
Group No: 134-3910
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1295252 | 1 TUBE AS-OIL | 1 | |
| 1A2029 | 2 BOLT (3/8-16X1.125-IN) | 2 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 5P7530 | 4 SEAL-O-RING | 1 | |
| 6J2245 | 5 SEAL-O-RING | 1 | |
| 0S1571 | 6 BOLT (3/8-16X1.75-IN) | 2 | |
| 1337224 | 7 TUBE AS-SUPPLY | 1 | |
| 1142687 | 8 SEAL-O-RING | 1 | |
| 4N7049 | 9 ELBOW | 1 | |
| 0S1594 | 10 BOLT (3/8-16X1-IN) | 2 | |
| 3P0650 | 11 SEAL-O-RING | 1 | |
| 0L1143 | 12 BOLT (3/8-16X2.5-IN) | 1 | |
| 9S8752 | 13 NUT-FULL (3/8-16-THD) | 1 | |
| 4P0692 | 14 CLAMP AS | 2 | |
| 1081434 | GROMMET | 1 | |
| 8R3600 | 15 ANGLE | 1 | |
| 0S0509 | 16 BOLT (3/8-16X0.75-IN) | 1 | |
| 6V8626 | 17 ELBOW | 1 | |
| 8L2746 | 18 SEAL-O-RING | 1 | |
| 1144427 | 19 SEAL-O-RING | 1 |
