System And Components
344-2149 CYLINDER HEAD GPS/N TXD2244-UP; THX20308-UP; THY1069-UP
Group No: 344-2149
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W2715 | 1 LOCK-RETAINER (INLET) | 24 | |
| 2A4429 | 2 LOCK-RETAINER (EXHAUST) | 24 | |
| 1632478 | 3 SEAL-VALVE STEM (EXHAUST) | 12 | |
| 1906115 | 4 SPRING-VALVE (INNER) | 12 | |
| 1906117 | 5 SPRING-VALVE (OUTER) | 12 | |
| 2112134 | 6 RETAINER | 12 | |
| 2170609 | 7 SEAT-VALVE SPRING | 6 | |
| 4901723 | 8 VALVE-EXHAUST | 12 | |
| 2418384 | 9 RETAINER | 12 | |
| 2418386 | 10 SPRING-VALVE (INNER) | 12 | |
| 2418385 | 11 SPRING-VALVE (OUTER) | 12 | |
| 2418387 | 12 SEAT | 6 | |
| 2418390 | 13 SEAL-VALVE STEM | 12 | |
| 4901726 | 14 VALVE-INLET | 12 | |
| 2595829 | 15 GUIDE-VALVE (STANDARD, INTAKE) | 12 | |
| 2543941 | GUIDE-VALVE (0.13-MM OS) | ||
| 2543942 | GUIDE-VALVE (0.5-MM OS) | ||
| 2604856 | 16 GUIDE-VALVE (STANDARD, EXHAUST) | 12 | |
| 2033237 | GUIDE-VALVE (0.13-MM OS, EXHAUST) | ||
| 2033238 | GUIDE-VALVE (0.5-MM OS, EXHAUST) | ||
| 3323619 | 17 CYLINDER HEAD AS | 1 | |
| 3196237 | 18 PLUG AS | 2 | |
| 2287096 | SEAL-O-RING | 1 | |
| 2717442 | PLUG | 1 | |
| 3893708 | 19 PLUG AS | 6 | |
| 2147568 | SEAL-O-RING | 1 | |
| 3603679 | PLUG-CONNECTOR (9/16-18-THD) | 1 | |
| 3960405 | 20 PLUG AS | 2 | |
| 6V6609 | SEAL-O-RING | 1 | |
| 3603680 | PLUG (3/4-16-THD) | 1 | |
| 8T6757 | 21 PLUG-PIPE | 2 |
