Assembly
100%

346-4295 GEAR GP-REARS/N TXD2244-UP; THX20308-UP; THY1069-UP

Group No: 346-4295
Part NumberPart NameQty
33375051 RETAINER1
27741052 GEAR AS-PUMP DRIVE (59-TEETH)(59-TEETH)2
4F6024PIN1
27741063 ADAPTER AS2
20986243A BUSHING1
28653034 GEAR AS-IDLER (74-TEETH)2
1W47384A BUSHING1
28653065 GEAR-CRANKSHAFT (63-TEETH)1
5P82456 WASHER-HARD (13.5X25.5X3-MM THK)12
6V33497 SEAL-O-RING2
6V56848 BOLT (M12X1.75X45-MM)12
8T78119 BOLT-SOCKET HEAD (M12X1.75X50-MM)8
346213810 RETAINER-GEAR1
