System And Components
277-4108 HOUSING GP-FLYWHEELS/N THY1069-UP
Group No: 277-4108
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1U8846 | 1 SEALANT-GASKET | ||
| 1753721 | 2 COVER | 1 | |
| 2143509 | 3 BRACKET AS | 1 | |
| 1707491 | STUD-WELD (M10X1.5X35-MM) | 1 | |
| 2774109 | 4 HOUSING GP-FLYWHEEL | 1 | |
| 2906204 | 5 HOUSING-ADAPTER | 1 | |
| 1705942 | 6 SEAL-O-RING | 1 | |
| 4M0189 | 7 SEAL-O-RING | 1 | |
| 5P8245 | 8 WASHER-HARD (13.5X25.5X3-MM THK) | 28 | |
| 6A5591 | 9 BOLT (M12X1.75X25-MM) | 1 | |
| 6V3668 | 10 BOLT (M12X1.75X30-MM) | 1 | |
| 6V5043 | 11 SEAL-O-RING | 1 | |
| 6V5134 | 12 SEAL-O-RING | 1 | |
| 6V5684 | 13 BOLT (M12X1.75X45-MM) | 11 | |
| 6V8197 | 14 BOLT (M12X1.75X40-MM) | 9 | |
| 6V8336 | 15 BOLT (M12X1.75X70-MM) | 6 |
