Assembly
100%

2W-0207 LINES GP-ENGINE OILS/N B7F100-UP

Group No: 2W-0207
Part NumberPart NameQty
1N33331 TUBE1
1W24472 ADAPTER-OUTLET1
2K49733 LOCKNUT (3/8-16-THD)2
2W10534 PLUG1
2W10555 ELBOW1
2W16356 SPRING1
2W19697 VALVE-BYPASS (OIL COOLER)1
2W72268 ADAPTER1
4B31409 COVER1
4W559610 COVER1
4W589011 PLUG1
6B093312 SPACER (10.31X19.05X6.35-MM THK)4
6B920213 SPRING2
7C921714 ELBOW (OIL COOLER BYPASS)1
7N541315 ELBOW1
7N541616 ELBOW (OUTLET)1
7N769717 PLUNGER AS (SEQUENCE VALVE)2
7M1808DOWEL1
8C344518 CAP-DUST1
8N199119 RING-RETAINING1
8N199220 RETAINER4
8N292921 COVER2
9M459422 SPACER (0.406X0.875X0.75-IN THK)2
100807523 CLAMP AS1
105429924 TUBE AS1
111382025 RING-RETAINING1
264045026 CLAMP AS1
061945627 SEAL-O-RING4
0L114328 BOLT (3/8-16X2.5-IN)6
0S157129 BOLT (3/8-16X1.75-IN)2
0S158830 BOLT (3/8-16X1.25-IN)5
0S159131 BOLT (3/8-16X1.5-IN)2
0S159432 BOLT (3/8-16X1-IN)20
109233233 SEAL-O-RING5
1A596434 BOLT (3/8-16X4.5-IN)4
3P065535 SEAL-O-RING3
5F489936 BOLT (3/8-16X5.5-IN)1
5M289437 WASHER-HARD (10.2X18.5X2.5-MM THK)16
5P489238 SEAL-O-RING1
5P584639 SEAL-O-RING1
5P781740 SEAL-O-RING1
6B507241 ADAPTER1
6V157242 CLIP (SLOT)2
6V157343 CLIP (TAB)2
6V157444 GROMMET2
6V390845 SEAL-O-RING1
6V504846 SEAL-O-RING3
8C344647 VALVE-SAMPLING1
8T676248 PLUG-PIPE (1/2-14-THD)1
8T676549 PLUG-PIPE (1/4-18-THD)1
9S418250 PLUG (7/16-20-THD)2
0S158852 BOLT (3/8-16X1.25-IN)1
8T676553 PLUG-PIPE (1/4-18-THD)2
8T676554 PLUG-PIPE (1/4-18-THD)1
6V458955 SEAL-O-RING1
8T676556 PLUG-PIPE (1/4-18-THD)1
9S419057 PLUG-O-RING (7/8-14-THD)1
3P076458 PLUG1
6V458959 SEAL-O-RING2
9S419060 PLUG-O-RING (7/8-14-THD)1
