2W-0207 LINES GP-ENGINE OILS/N B7F697-789

Group No: 2W-0207
Part NumberPart NameQty
1N33331 TUBE1
1W24472 ADAPTER-OUTLET1
2W10533 PLUG1
2W16354 SPRING1
2W19695 VALVE-BYPASS (OIL COOLER)1
4W58906 PLUG1
6B92027 SPRING2
7C92178 ELBOW (OIL COOLER BYPASS)1
7N54169 ELBOW (OUTLET)1
7N769710 PLUNGER AS (SEQUENCE VALVE)2
7M1808DOWEL1
8N199211 RETAINER2
8N292912 COVER2
100807513 CLAMP AS1
105429914 TUBE AS1
111382015 RING-RETAINING1
264045016 CLAMP AS1
359412217 ELBOW1
359412318 ADAPTER (TURBOCHARGER OIL)1
361709719 RING1
361709820 FLANGE1
369950921 ELBOW-OIL COOLER (INLET)1
0L114322 BOLT (3/8-16X2.5-IN)6
0S157123 BOLT (3/8-16X1.75-IN)4
0S158824 BOLT (3/8-16X1.25-IN)5
0S159125 BOLT (3/8-16X1.5-IN)2
0S159426 BOLT (3/8-16X1-IN)18
109233227 SEAL-O-RING5
1A596428 BOLT (3/8-16X4.5-IN)4
228709729 SEAL-O-RING1
2K497330 LOCKNUT (3/8-16-THD)2
3P065531 SEAL-O-RING3
4B314032 COVER1
4W559633 COVER1
5F489934 BOLT (3/8-16X5.5-IN)1
5M289435 WASHER-HARD (10.2X18.5X2.5-MM THK)16
5P489236 SEAL-O-RING1
5P584637 SEAL-O-RING1
6B093338 SPACER (10.31X19.05X6.35-MM THK)4
6B507239 ADAPTER1
6V157240 CLIP (SLOT)2
6V157341 CLIP (TAB)2
6V157442 GROMMET2
6V390843 SEAL-O-RING1
6V436844 SEAL-O-RING4
6V504845 SEAL-O-RING3
8C344546 CAP-DUST1
8C344647 VALVE-SAMPLING1
8T676248 PLUG-PIPE (1/2-14-THD)1
8T676549 PLUG-PIPE (1/4-18-THD)1
9S418250 PLUG (7/16-20-THD)2
9S419051 PLUG-O-RING (7/8-14-THD)1
0S158852 BOLT (3/8-16X1.25-IN)1
8T676553 PLUG-PIPE (1/4-18-THD)2
8T676554 PLUG-PIPE (1/4-18-THD)1
6V458955 SEAL-O-RING1
8T676556 PLUG-PIPE (1/4-18-THD)1
9S419057 PLUG-O-RING (7/8-14-THD)1
3P076458 PLUG1
6V458959 SEAL-O-RING2
