381-8702 LINES GP-ENGINE OILS/N B7F1-UP; 8BR1-UP

Group No: 381-8702
Part NumberPart NameQty
1N33331 TUBE1
1W24472 ADAPTER-OUTLET1
2W10533 PLUG1
2W16354 SPRING1
2W19695 VALVE-BYPASS (OIL COOLER)1
3P07646 PLUG1
4W58907 PLUG1
6B92028 SPRING2
7C92179 ELBOW (OIL COOLER BYPASS)1
7N541610 ELBOW (OUTLET)1
7N769711 PLUNGER AS (SEQUENCE VALVE)2
7M1808DOWEL1
361709712 RING1
8N199213 RETAINER2
8N292914 COVER2
100807515 CLAMP AS1
105429916 TUBE AS1
111382017 RING-RETAINING1
264045018 CLAMP AS1
359412219 ELBOW1
359412320 ADAPTER (TURBOCHARGER OIL)1
369950921 ELBOW-OIL COOLER (INLET)1
0L114322 BOLT (3/8-16X2.5-IN)6
165393123 BOLT (3/8-16X1.75-IN)4
0S158824 BOLT (3/8-16X1.25-IN)6
165392925 BOLT (3/8-16X1.5-IN)2
0S159426 BOLT (3/8-16X1-IN)18
109233227 SEAL-O-RING5
1A596428 BOLT (3/8-16X4.5-IN)4
228709729 SEAL-O-RING1
2K497330 LOCKNUT (3/8-16-THD)2
3P065531 SEAL-O-RING3
4B314032 COVER1
4W559633 COVER1
5F489934 BOLT (3/8-16X5.5-IN)1
5M289435 WASHER-HARD (10.2X18.5X2.5-MM THK)20
5P489236 SEAL-O-RING1
5P584637 SEAL-O-RING1
6B093338 SPACER (10.31X19.05X6.35-MM THK)4
6B507239 ADAPTER1
6V157240 CLIP (SLOT)2
6V157341 CLIP (TAB)2
6V157442 GROMMET2
6V390843 SEAL-O-RING1
6V436844 SEAL-O-RING4
6V458945 SEAL-O-RING1
6V504846 SEAL-O-RING3
8C344547 CAP-DUST1
8C344648 VALVE-SAMPLING1
8T676249 PLUG-PIPE (1/2-14-THD)1
8T676550 PLUG-PIPE (1/4-18-THD)2
9S418251 PLUG (7/16-20-THD)2
361709852 FLANGE1
