System And Components
285-0724 LINES GP-AIR -AFTERCOOLERS/N MSY1-234
Group No: 285-0724
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1356261 | 1 CLAMP | 8 | |
| 2086135 | 2 CLIP (SLOT) | 16 | |
| 2086136 | 3 CLIP (TAB) | 16 | |
| 2162211 | 4 CLAMP | 40 | |
| 2556264 | 5 GASKET | 1 | |
| 2684743 | 6 HOSE | 10 | |
| 2733538 | 7 HOSE | 2 | |
| 3002396 | 8 TUBE AS | 1 | |
| 3245885 | 9 BRACKET | 2 | |
| 3085286 | 10 BRACKET | 1 | |
| 3085287 | 11 BRACKET | 1 | |
| 3085300 | 12 BRACKET | 1 | |
| 3085301 | 13 BRACKET | 1 | |
| 3085314 | 14 TUBE AS | 1 | |
| 3085316 | 15 TUBE AS | 1 | |
| 3085319 | 16 TUBE | 1 | |
| 3106878 | 17 PLATE | 2 | |
| 3106879 | 18 PLATE | 2 | |
| 3113230 | 19 TUBE | 1 | |
| 3113231 | 20 TUBE | 2 | |
| 3113232 | 21 TUBE | 1 | |
| 3113233 | 22 TUBE | 1 | |
| 4L9337 | 23 BOLT (3/8-16X1.5-IN) | 16 | |
| 5M3062 | 24 BOLT (3/8-16X0.75-IN) | 16 | |
| 5P1075 | 25 WASHER-HARD (10.2X22.5X3-MM THK) | 48 | |
| 6V8189 | 26 NUT (5/16-18-THD) | 8 | |
| 6V8801 | 27 NUT (3/8-16-THD) | 16 | |
| 8C3121 | 28 BOLT (5/16-18X1.5-IN) | 8 | |
| 8T4224 | 29 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 5M6214 | 30 PLUG (1/8-27 PTF) | 2 |
