System And Components
Assembly
100%

311-8521 LINES GP-AIR -UPPERS/N B7F100-326

Group No: 311-8521
Part NumberPart NameQty
9S87521 NUT-FULL (3/8-16-THD)4
5G43132 SPACER (10.34X15.88X12-MM THK)8
32158955 SHIELD AS4
7N69866 SUPPORT4
8N52547 HOSE-REDUCER4
17454159 CLAMP4
191601510 BRACKET2
197973211 U-BOLT4
208613512 CLIP (SLOT)4
208613613 CLIP (TAB)4
268474314 HOSE4
272240015 ELBOW2
272319616 TUBE2
272347517 BRACKET2
294524818 ELBOW2
311056019 TUBE AS1
311056120 TUBE AS1
0S158821 BOLT (3/8-16X1.25-IN)8
0S159122 BOLT (3/8-16X1.5-IN)4
216221123 CLAMP16
2K497324 LOCKNUT (3/8-16-THD)8
3J190725 SEAL-O-RING2
5M289426 WASHER-HARD (10.2X18.5X2.5-MM THK)24
5P107527 WASHER-HARD (10.2X22.5X3-MM THK)16
6V194328 BOLT-HIGH TEMPERATURE (3/8-16X1.125-IN)8
6V391729 SEAL-O-RING8
6V880130 NUT (3/8-16-THD)8
8T489631 WASHER-HARD (10.2X18.5X2.5-MM THK)8
8T937932 BOLT (3/8-16X4.25-IN)8
9B723733 BOLT (3/8-16X1.25-IN)8
9S419134 PLUG (9/16-18-THD)2
5N442835 BOOT2
5N443236 BOOT2
5P386037 CLAMP-HOSE2
5P486938 CLAMP-HOSE6
338858739 BRACKET2
