463-7674 LINES GP-AIRS/N 8BR1-UP

Group No: 463-7674
Part NumberPart NameQty
0S05091 BOLT (3/8-16X0.75-IN)6
0S15902 BOLT (3/8-16X2-IN)6
16539293 BOLT (3/8-16X1.5-IN)24
0S15944 BOLT (3/8-16X1-IN)12
0S16195 BOLT (3/8-16X3-IN)2
0T05736 BOLT (3/8-16X2.75-IN)2
10974117 SEAL-O-RING2
12369798 CLAMP-V BAND2
12781129 SUPPORT-EXHAUST PIPE (LH)1
127811310 SUPPORT-EXHAUST PIPE (RH)1
129952711 BAR2
146738312 FLANGE2
155043713 COVER1
155054414 ELBOW1
155054515 ELBOW1
156626116 BRACKET2
156983017 ELBOW1
165419018 COUPLING-ELBOW2
180742819 ADAPTER1
186417120 ELBOW (AIR INLET)1
1A202921 BOLT (3/8-16X1.125-IN)2
1S115022 SPACER (0.391X0.5X0.19-IN THK)12
1T072023 BOLT-12 POINT HEAD (3/8-16X1.25-IN)48
283959924 MANIFOLD (AIR INLET)1
2A463925 BOLT (3/8-16X1.625-IN)24
2N276526 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)8
348566127 PLATE1
360367928 PLUG-CONNECTOR (9/16-18-THD)12
391216729 LOCKNUT-FLANGE (3/8X16-THD)20
434832130 GASKET-MANIFOLD12
461575231 ELBOW-AIR INLET10
586248432 ELBOW-AIR INLET2
4S589833 SEAL-O-RING12
4W022634 ADAPTER2
5D595735 SEAL-O-RING2
5M289436 WASHER-HARD (10.2X18.5X2.5-MM THK)118
5P824537 WASHER-HARD (13.5X25.5X3-MM THK)2
6V325038 SEAL-O-RING12
6V391739 SEAL-O-RING8
6V510140 SEAL-O-RING12
7C819941 FLANGE12
7L319542 BOLT-HIGH TEMPERATURE (3/8-16X1.75-IN)12
7N508743 GASKET2
7W314544 PLATE4
8T676245 PLUG-PIPE (1/2-14-THD)5
8T676446 PLUG-PIPE (1/8-27-THD)4
9F277347 BOLT (3/8-16X8.5-IN)10
9X645848 WASHER-HARD (10.2X22.5X3-MM THK)4
2B200649 BOLT (1/2-13X4.75-IN)2
238508050 SEAL-O-RING2
360369351 PLUG (3/4-16-THD)2
