System And Components
285-0795 PIPE GP-EXHAUSTS/N MSY1-143
Group No: 285-0795
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5G3845 | 1 BOSS (12.8X25X50-MM THK) | 1 | |
| 7E8452 | 2 CLAMP | 1 | |
| 1546339 | 3 PLATE | 1 | |
| 2420799 | 4 BELLOWS AS | 2 | |
| 2420810 | 5 CLAMP | 1 | |
| 2516357 | 6 SHIELD-HEAT | 2 | |
| 3028136 | 7 CLAMP-BAND | 6 | |
| 3106876 | 8 FLANGE AS | 2 | |
| 3113990 | 9 TUBE AS | 1 | |
| 3113994 | 10 PLATE | 1 | |
| 3114000 | 11 TUBE AS | 1 | |
| 3114001 | 12 TUBE AS | 1 | |
| 3114007 | 13 BRACKET AS | 1 | |
| 3114011 | 14 BRACKET AS | 1 | |
| 2453512 | 15 GASKET (EXHAUST) | 2 | |
| 4L6454 | 16 BOLT (3/8-16X1-IN) | 10 | |
| 5P1075 | 17 WASHER-HARD (10.2X22.5X3-MM THK) | 11 | |
| 6V8801 | 18 NUT (3/8-16-THD) | 16 | |
| 8T2501 | 19 BOLT (3/8-16X2-IN) | 16 | |
| 8T4896 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 32 | |
| 8T7008 | 21 BOLT (3/8-16X3-IN) | 1 |
