System And Components
309-9626 PIPE GP-EXHAUSTS/N MSY1-UP
Group No: 309-9626
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5G3845 | 1 BOSS (12.8X25X50-MM THK) | 1 | |
| 5T2762 | 2 SPRING | 1 | |
| 5T3367 | 3 ELBOW | 1 | |
| 5T3369 | 4 PISTON | 1 | |
| 6G7031 | 5 ELBOW | 1 | |
| 6G7038 | 6 RING-SEAL | 1 | |
| 7K1270 | 7 WASHER (17X38X8-MM THK) | 8 | |
| 9D2836 | 8 LOCK | 3 | |
| 2420811 | 9 CLAMP | 1 | |
| 3214298 | 10 PLATE AS | 1 | |
| 3214303 | 11 BRACKET AS | 1 | |
| 3214309 | 12 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 2420810 | CLAMP | 1 | |
| 3214369 | 13 TUBE AS | 1 | |
| 0L1351 | 14 BOLT (3/8-16X0.875-IN) | 6 | |
| 2D5238 | 15 STUD-TAPERLOCK (5/8-11X2.5-IN) | 4 | |
| 4B3586 | 16 SETSCREW (1/2-13X2-IN) | 2 | |
| 4L6454 | 17 BOLT (3/8-16X1-IN) | 4 | |
| 5P1075 | 18 WASHER-HARD (10.2X22.5X3-MM THK) | 5 | |
| 6V8188 | 19 NUT (1/2-13-THD) | 2 | |
| 7X0345 | 20 BOLT (5/8-11X1.75-IN) | 4 | |
| 7X0448 | 21 NUT (5/8-11-THD) | 4 | |
| 8T4122 | 22 WASHER-HARD (17X32X3.5-MM THK) | 12 | |
| 8T4223 | 23 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T7008 | 24 BOLT (3/8-16X3-IN) | 1 | |
| 8T8917 | 25 BOLT (1/2-13X1.25-IN) | 6 | |
| 8T9393 | 26 BOLT (5/8-11X1.5-IN) | 4 | |
| 9X6458 | 27 WASHER-HARD (10.2X22.5X3-MM THK) | 6 |
