System And Components
309-9608 LINES GP-STEERINGS/N MSY1-127
Group No: 309-9608
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2G8874 | 1 CLAMP | 1 | |
| 2G8875 | 2 CLAMP | 1 | |
| 2G8895 | 3 BRACKET AS | 1 | |
| 1F0750 | NUT-WELD (3/8-16-THD) | 1 | |
| 3R3802 | 4 CLIP | 1 | |
| 6D0837 | 5 ELBOW | 1 | |
| 6G8532 | 6 GUARD AS | 1 | |
| 6V0852 | 7 CAP-DUST | 1 | |
| 7I4690 | 8 PLATE AS | 1 | |
| 8D7296 | 9 JUNCTION BLOCK | 2 | |
| 8W5148 | 10 HOSE AS | 1 | |
| 8W5156 | 11 HOSE AS | 1 | |
| 8W5161 | 12 MANIFOLD | 1 | |
| 8X2701 | 13 PLATE | 2 | |
| 8X5974 | 14 MANIFOLD | 1 | |
| 1134339 | 15 SPACER (10.5X18X21-MM THK) | 2 | |
| 1509037 | 16 BAR | 1 | |
| 1518723 | 17 TUBE AS | 1 | |
| 1645563 | 18 UNION AS | 1 | |
| 5P9560 | UNION | 1 | |
| 3D2824 | SEAL-O-RING | 2 | |
| 1760393 | 19 FITTING AS | 1 | |
| 8X7851 | FITTING-ORIFICE | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1766448 | 20 VALVE GP-CHECK (STEERING) | 1 | |
| 2977968 | 21 FITTING | 1 | |
| 2977969 | 22 CAP-DUST | 1 | |
| 3148485 | 23 HOSE AS | 1 | |
| 3148486 | 24 HOSE AS | 1 | |
| 3148487 | 25 HOSE AS | 1 | |
| 3148488 | 26 HOSE AS | 1 | |
| 3148706 | 27 BLOCK | 1 | |
| 1061793 | 28 STUD-TAPERLOCK (3/8-16X2.36-IN) | 5 | |
| 1488327 | 29 CONNECTOR AS | 1 | |
| 6V8637 | CONNECTOR | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488339 | 30 CONNECTOR AS | 3 | |
| 6V8716 | CONNECTOR (STRAIGHT) | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488347 | 31 ELBOW AS | 2 | |
| 6V9007 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488358 | 32 ELBOW AS | 1 | |
| 6V8624 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488364 | 33 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488408 | 34 PLUG AS | 1 | |
| 9S4183 | PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 1504049 | 35 ELBOW AS | 1 | |
| 8T4149 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1518724 | 36 TUBE AS | 1 | |
| 1518725 | 37 TUBE AS | 1 | |
| 1518726 | 38 TUBE AS | 1 | |
| 1536237 | 39 ELBOW AS | 4 | |
| 6V9004 | ELBOW | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1645567 | 40 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1724621 | 41 ADAPTER AS | 1 | |
| 6V0301 | ADAPTER | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1760391 | 42 ADAPTER AS | 2 | |
| 8V7764 | ADAPTER-O-RING | 1 | |
| 6K6307 | SEAL-O-RING | 1 | |
| 1P4576 | 43 FLANGE-HALF | 12 | |
| 1P4578 | 44 FLANGE-HALF | 8 | |
| 1P4579 | 45 FLANGE-HALF | 2 | |
| 1P4582 | 46 FLANGE-HALF | 4 | |
| 3G4667 | 47 VALVE GP-RELIEF (STEERING) | 1 | |
| 4J0520 | 48 SEAL-O-RING | 1 | |
| 4J0522 | 49 SEAL-O-RING | 8 | |
| 4J0524 | 50 SEAL-O-RING | 1 | |
| 4J0527 | 51 SEAL-O-RING | 2 | |
| 4J5267 | 52 SEAL-O-RING | 8 | |
| 4L6459 | 53 BOLT (3/8-16X2.5-IN) | 2 | |
| 4L9337 | 54 BOLT (3/8-16X1.5-IN) | 1 | |
| 5K9090 | 55 SEAL-O-RING | 2 | |
| 5M3062 | 56 BOLT (3/8-16X0.75-IN) | 2 | |
| 5P1075 | 57 WASHER-HARD (10.2X22.5X3-MM THK) | 18 | |
| 5P2566 | 58 BOLT (1/2-13X1.5-IN) | 6 | |
| 5P7466 | 59 CLIP (SLOT) | 10 | |
| 5P7467 | 60 CLIP (TAB) | 10 | |
| 5P7468 | 61 CLIP (SLOT) | 6 | |
| 5P7469 | 62 CLIP (TAB) | 6 | |
| 5P7470 | 63 CLIP (SLOT) | 7 | |
| 5P7471 | 64 CLIP (TAB) | 7 | |
| 5P8112 | 65 GROMMET | 10 | |
| 5P8182 | 66 GROMMET (46-MM ID) | 6 | |
| 5P8444 | 67 GROMMET (37-MM ID) | 6 | |
| 5P9938 | 68 BOLT-HEAD LOCKING (3/8-16X1.375-IN) | 1 | |
| 5S7379 | 69 BOLT (3/8-16X0.875-IN) | 5 | |
| 5S7382 | 70 BOLT (3/8-16X1.375-IN) | 24 | |
| 6E6298 | 71 VALVE GP-SOLENOID & RELIEF (STEERING) | 1 | |
| 6V8188 | 72 NUT (1/2-13-THD) | 2 | |
| 6V8398 | 73 SEAL-O-RING | 1 | |
| 6V8556 | 74 NUT (1-3/16-12-THD) | 1 | |
| 6V8801 | 75 NUT (3/8-16-THD) | 8 | |
| 6V8942 | 76 REDUCER-O-RING | 1 | |
| 6V9746 | 77 SEAL-O-RING | 4 | |
| 6V9839 | 78 TEE-SWIVEL | 1 | |
| 7G3832 | 79 GROMMET | 1 | |
| 7G3833 | 80 CLIP (TAB) | 1 | |
| 7G3834 | 81 CLIP (SLOT) | 1 | |
| 7K2828 | 82 CLIP | 4 | |
| 7X0288 | 83 BOLT (3/8-16X1.625-IN) | 2 | |
| 7X0290 | 84 BOLT (3/8-16X3.5-IN) | 2 | |
| 7X0312 | 85 BOLT (7/16-14X2.5-IN) | 2 | |
| 7X0315 | 86 BOLT (7/16-14X3.25-IN) | 6 | |
| 8T2502 | 87 BOLT (3/8-16X1.125-IN) | 4 | |
| 8T4223 | 88 WASHER-HARD (13.5X25.5X3-MM THK) | 17 | |
| 8T4896 | 89 WASHER-HARD (10.2X18.5X2.5-MM THK) | 46 | |
| 8T5360 | 90 WASHER (12X22.5X2.5-MM THK) | 20 | |
| 8T7008 | 91 BOLT (3/8-16X3-IN) | 3 | |
| 8T8915 | 92 BOLT (3/8-16X3.25-IN) | 2 | |
| 8T8916 | 93 BOLT (7/16-14X1.5-IN) | 12 | |
| 8T8919 | 94 BOLT (1/2-13X1.75-IN) | 9 | |
| 8T9101 | 95 BOLT (3/8-16X2.75-IN) | 1 | |
| 8T9379 | 96 BOLT (3/8-16X4.25-IN) | 3 | |
| 8W3771 | 97 HOSE AS | 2 | |
| 8W4315 | 98 HOSE AS | 2 | |
| 8W5149 | 99 HOSE AS | 1 | |
| 8W5150 | 100 HOSE AS | 1 | |
| 8W5151 | 101 HOSE AS | 1 | |
| 8W5152 | 102 HOSE AS | 1 | |
| 8W5153 | 103 HOSE AS | 1 | |
| 8W5155 | 104 HOSE AS | 1 | |
| 8X6280 | 105 HOSE AS | 1 | |
| 9B7237 | 106 BOLT (3/8-16X1.25-IN) | 4 |
