System And Components
524-7241 ACCUMULATOR GP-HYDRAULIC -CHARGEDS/N MSY1-UP
Group No: 524-7241
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3242404 | 1 FILM-INFORMATION (HYDRAULIC ACCUMULATOR) | 1 | |
| 9F4446 | 2 SEAL-O-RING | 1 | |
| 2222367 | 3 VALVE GP-ACCUMULATOR CHARGING | 1 | |
| 1903850 | CORE | 1 | |
| 1694805 | 4 RING | 1 | |
| 1694806 | 5 SPACER (80X101.6X7.2-MM THK) | 1 | |
| 1694807 | 6 NUT (3-1/8-12-THD) | 1 | |
| 1694809 | 7 NUT (7/8-14-THD) | 1 | |
| 1694810 | 8 COVER | 1 | |
| 1694814 | 9 WASHER (80.6X88.6X1.8-MM THK) | 1 | |
| 1694815 | 10 RING | 1 | |
| 1696727 | 11 POPPET | 1 | |
| 1696729 | 12 SPRING | 1 | |
| 1696730 | 13 SLEEVE | 1 | |
| 1482599 | 14 KIT-REPAIR (ACCUMULATOR BLADDER) | 1 | |
| 1741739 | 15 FITTING | 1 | |
| 2F8616 | 16 NUT-SELF LOCKING (3/8-24-THD) | 1 | |
| 3J1907 | 17 SEAL-O-RING | 1 | |
| 1694812 | 18 SEAL | 1 | |
| 5P4482 | 19 PLUG | 1 |
