System And Components
243-5157 AIR CLEANER GPS/N JXP1-UP
Group No: 243-5157
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 5P0600 | 2 CLAMP-HOSE | 2 | |
| 8N5991 | 3 HOSE | 2 | |
| 9N0720 | 4 ELBOW-AIR INLET | 4 | |
| 1505030 | 5 INDICATOR-AIR FILTER CHANGE | 1 | |
| 2522230 | 6 TUBE | 1 | |
| 2522231 | 7 TUBE | 1 | |
| 2539105 | 8 BRACKET AS | 1 | |
| 2543566 | 9 AIR CLEANER GP | 2 | |
| 2544293 | 10 CAP GP-AIR CLEANER | 2 | |
| 5P0600 | CLAMP-HOSE | 1 | |
| 2545719 | 11 MANIFOLD AS | 1 | |
| 2545723 | 12 BRACKET | 1 | |
| 2545724 | 13 BRACKET | 1 | |
| 2559392 | 14 PIPE-EXTENSION | 1 | |
| 3123197 | 15 BRACKET AS | 1 | |
| 3B6487 | COUPLING (PIPE) | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 3 | |
| 3166504 | 16 PIPE-EXTENSION | 1 | |
| 1696713 | 17 ADAPTER AS | 1 | |
| 7J0204 | SEAL-O-RING | 1 | |
| 2162212 | 18 CLAMP | 8 | |
| 2338484 | 19 CLAMP (BOLT SPRING) | 4 | |
| 3B6552 | 20 ELBOW-PIPE | 1 | |
| 4P7428 | 21 CLIP (LADDER) | 1 | |
| 5P2948 | 22 FITTING AS | 2 | |
| 4K9821 | SLEEVE | 1 | |
| 4K9822 | NUT (5/16-24-THD) | 1 | |
| 6V2686 | 23 CLIP | 1 | |
| 7X7729 | 24 WASHER (11X25X3-MM THK) | 2 | |
| 8B4884 | 25 ELBOW | 1 | |
| 8T4121 | 26 WASHER-HARD (11X21X2.5-MM THK) | 13 | |
| 8T4136 | 27 BOLT (M10X1.5X25-MM) | 15 | |
| 8T4139 | 28 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4223 | 29 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4779 | 30 BOLT (M16X2X35-MM) | 6 | |
| 9X8257 | 31 WASHER (17.5X30X3.5-MM THK) | 6 | |
| 5P5630 | 32 TUBE (1.4-M) |
