System And Components
383-1739 CAMSHAFT GPS/N D85106-UP; B7F790-UP
Group No: 383-1739
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4W6664 | 1 PLATE AS-TIMING | 2 | |
| 7N3216 | 2 SPACER (35.035X84X12-MM THK) | 2 | |
| 1179308 | 3 PLATE | 2 | |
| 1285993 | 4 WASHER-THRUST | 2 | |
| 2835732 | 5 CAMSHAFT AS (FRONT, LH) | 1 | |
| 4N1650 | DOWEL | 1 | |
| 2835734 | 6 CAMSHAFT AS (REAR, LH) | 1 | |
| 5B5821 | DOWEL | 1 | |
| 2835736 | 7 CAMSHAFT AS (FRONT, RH) | 1 | |
| 5B5821 | DOWEL | 1 | |
| 2835738 | 8 CAMSHAFT AS (REAR, RH) | 1 | |
| 4N1650 | DOWEL | 1 | |
| 0S0509 | 9 BOLT (3/8-16X0.75-IN) | 2 | |
| 1A2029 | 10 BOLT (3/8-16X1.125-IN) | 4 | |
| 5M2894 | 11 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P0076 | 12 BOLT-12 POINT HEAD (3/8-16X1.5-IN) | 16 | |
| 2503444 | 13 FILM-INFORMATION (STANDARD ROTATION) | 1 |
