System And Components
393-6232 DRIVE GP-ACCESSORYS/N D851-UP; M4J1-UP
Group No: 393-6232
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1W4736 | 1 GASKET-COVER | 1 | |
| 4P3738 | 2 SHAFT AS | 2 | |
| 8T2153 | SETSCREW-SOCKET (1/4-28X0.31-IN) | 1 | |
| 4P3834 | 3 GASKET | 1 | |
| 7E6625 | 4 COVER | 1 | |
| 7N8525 | 5 WASHER-THRUST | 4 | |
| 8N2757 | 6 ADAPTER AS | 1 | |
| 7N3011 | 6A BUSHING | 1 | |
| 8N2802 | 7 COVER | 1 | |
| 1078748 | 8 GEAR-AUXILIARY DRIVE (75-TEETH) | 1 | |
| 1078749 | 9 GEAR-AUXILIARY DRIVE (83-TEETH) | 1 | |
| 1299476 | 10 ADAPTER AS | 1 | |
| 7N3011 | 10A BUSHING | 1 | |
| 4171553 | 11 HOUSING AS-GEAR | 1 | |
| 3F6795 | DOWEL | 6 | |
| 7E6619 | HOUSING-ACCESSORY DRIVE | 1 | |
| 7N2047 | DOWEL | 2 | |
| 7N3011 | 11A BUSHING | 3 | |
| 0L1026 | 12 PLUG-CUP | 3 | |
| 0S1588 | 13 BOLT (3/8-16X1.25-IN) | 24 | |
| 0S1591 | 14 BOLT (3/8-16X1.5-IN) | 2 | |
| 0S1594 | 15 BOLT (3/8-16X1-IN) | 6 | |
| 1F7958 | 16 NUT-FULL (1/2-13-THD) | 8 | |
| 1T0765 | 17 BOLT (3/8-16X1-IN) | 20 | |
| 2D8154 | 18 STUD-TAPERLOCK (1/2-13X2.36-IN) | 8 | |
| 2J6274 | 19 SEAL-O-RING | 1 | |
| 3F5792 | 20 SEAL-O-RING | 2 | |
| 5M2894 | 21 WASHER-HARD (10.2X18.5X2.5-MM THK) | 24 | |
| 5P8245 | 22 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 7X7731 | 23 PLUG-PIPE (3/4-14-THD) | 2 | |
| 8M5253 | 24 SEAL-O-RING | 2 | |
| 8T6757 | 25 PLUG-PIPE | 3 | |
| 9S8752 | 26 NUT-FULL (3/8-16-THD) | 2 | |
| 9Y8386 | 27 GASKET | 1 | |
| 4K0367 | 28 NUT-FULL (5/8-11-THD) | 2 | |
| 5P8247 | 29 WASHER-HARD (17X32X3.5-MM THK) | 2 | |
| 3D8439 | 30 STUD (5/8-11X3.4-IN) | 2 |
