System And Components
163-2592 DRIVE GP-FANS/N DMC1-UP
Group No: 163-2592
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1098044 | 1 PLUG-PIPE | 1 | |
| 1098048 | 2 SLEEVE-WEAR | 1 | |
| 1098052 | 3 SEAL-OIL | 2 | |
| 1098041 | 4 RETAINER-BEARING | 1 | |
| 1098042 | 5 RING-SNAP | 1 | |
| 1098053 | 6 SEAL-RING | 2 | |
| 1098043 | 7 PISTON-CLUTCH | 1 | |
| 1098054 | 8 SEAL-RING | 1 | |
| 1098051 | 9 SEAL-RING | 1 | |
| 1335913 | 10 PLATE AS-CLUTCH | 7 | |
| 1098046 | 11 PLATE-CLUTCH | 7 | |
| 1335908 | 12 ADAPTER | 1 | |
| 5M2894 | 13 WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 1098058 | 14 RETAINER-BEARING | 1 | |
| 1098065 | 15 RING-SNAP | 1 | |
| 1098066 | 16 RING-SNAP | 1 | |
| 1098060 | 17 RING-SNAP | 1 | |
| 1098061 | 18 TUBE-OIL | 2 | |
| 1098045 | 19 HUB-SPLINED | 1 | |
| 1654852 | 20 SEAL-O-RING | 2 | |
| 1098090 | 21 WASHER-SPRING | 1 | |
| 1098085 | 22 RING-SNAP | 1 | |
| 1098087 | 23 SHIM-ANNULAR | 1 | |
| 1098088 | 24 ADAPTER-PULLEY | 1 | |
| 1A2029 | 25 BOLT (3/8-16X1.125-IN) | 16 | |
| 0061800 | 26 SCREW (5/8-11X1-IN) | 8 | |
| 1335909 | 27 SEAL-O-RING | 1 | |
| 1261133 | 28 SENSOR GP-SPEED (FAN DRIVE) | 1 | |
| 1749349 | 29 SHAFT AS | 1 | |
| 1098047 | 29A RETAINER | 1 | |
| 1098048 | 29B SLEEVE-WEAR | 1 | |
| 1749347 | 29C DOWEL | 1 | |
| 1776890 | 30 BALL BEARING | 1 | |
| 1609828 | 31 HUB AS | 1 | |
| 1098047 | 31A RETAINER | 1 | |
| 1098056 | 31B BUSHING | 1 | |
| 1098069 | 31C SLEEVE-WEAR | 1 | |
| 1240327 | 31D MAGNET AS | 1 | |
| 1335907 | 31E BEARING | 1 | |
| 1628283 | 31F SETSCREW (8-32X1-IN) | 1 | |
| 1749372 | 31G DOWEL | 1 | |
| 1776889 | 32 BALL BEARING | 1 | |
| 1749339 | 33 SPACER-BEARING (3.95-MM THK) | 1 | |
| 1223188 | KIT-SEAL (VARIABLE SPEED FAN DRIVE) | 1 | |
| 1749351 | KIT-REPAIR (VARIABLE SPEED FAN DRIVE) | 1 |
