System And Components
417-4085 GEAR GP-REAR -CAM DRIVES/N D851-UP
Group No: 417-4085
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7E5324 | 1 RING | 1 | |
| 1011365 | 2 PLATE-THRUST | 1 | |
| 1011367 | 3 SHAFT-IDLER | 2 | |
| 1011368 | 4 WASHER-THRUST (19.5X106X1.9-MM THK) | 2 | |
| 1011370 | 5 GEAR-CRANKSHAFT (92-TEETH) | 1 | |
| 1755197 | 6 GEAR AS-IDLER (69-TEETH) | 2 | |
| 1259751 | BUSHING | 1 | |
| 1755201 | 7 GEAR-CAMSHAFT (70-TEETH) | 2 | |
| 3937459 | 8 GEAR AS-IDLER (CLUSTER) | 1 | |
| 4P5460 | 8A BUSHING | 1 | |
| 3974059 | 9 SHAFT-CLUSTER GEAR | 1 | |
| 0L1351 | 10 BOLT (3/8-16X0.875-IN) | 4 | |
| 1B4367 | 11 BOLT (5/8-11X3-IN) | 4 | |
| 3S1307 | 12 BOLT-12 POINT HEAD (3/8-16X2-IN) | 12 | |
| 4W4586 | 13 PLATE | 1 | |
| 5P8248 | 14 WASHER-HARD (20X36.5X3.5-MM THK) | 2 | |
| 8M2530 | 15 BOLT-12 POINT HEAD (1/2-13X1.25-IN) | 4 | |
| 8S2331 | 16 BOLT-12 POINT HEAD (5/8-11X2-IN) | 2 | |
| 9X8887 | 17 BOLT (3/4-10X3-IN) | 2 |
