System And Components
312-4174 LINES GP-AIR -LOWERS/N D851-UP; B7F1-UP
Group No: 312-4174
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6W6672 | 1 SPACER (10.5X20X38-MM THK) | 6 | |
| 7C7909 | 2 ELBOW (AIR INLET) | 10 | |
| 7C7910 | 3 ELBOW (AIR INLET) | 2 | |
| 7C8199 | 4 FLANGE | 12 | |
| 7N5080 | 5 GASKET-MANIFOLD | 12 | |
| 1299527 | 6 BAR | 2 | |
| 3485661 | 7 PLATE | 1 | |
| 2032163 | 8 SPACER (10.5X22.5X21.35-MM THK) | 4 | |
| 4289129 | 9 GASKET (SPIRAL WOUND) | 1 | |
| 2654433 | 12 COVER | 1 | |
| 2705323 | 13 MANIFOLD (AIR INLET) | 1 | |
| 2721604 | 14 COVER | 1 | |
| 3031541 | 15 SEAL-O-RING | 1 | |
| 0L2070 | 16 BOLT (3/8-16X2.25-IN) | 4 | |
| 0S0509 | 17 BOLT (3/8-16X0.75-IN) | 6 | |
| 0S1590 | 18 BOLT (3/8-16X2-IN) | 6 | |
| 1653929 | 19 BOLT (3/8-16X1.5-IN) | 24 | |
| 0S1619 | 20 BOLT (3/8-16X3-IN) | 6 | |
| 1T0720 | 22 BOLT-12 POINT HEAD (3/8-16X1.25-IN) | 48 | |
| 3139550 | 23 STUD-TAPERLOCK (3/8-16X2.165-IN) | 4 | |
| 2A4639 | 24 BOLT (3/8-16X1.625-IN) | 24 | |
| 3K0360 | 25 SEAL-O-RING | 1 | |
| 4S5898 | 26 SEAL-O-RING | 12 | |
| 5M2894 | 27 WASHER-HARD (10.2X18.5X2.5-MM THK) | 116 | |
| 6V5101 | 29 SEAL-O-RING | 12 | |
| 8T6762 | 30 PLUG-PIPE (1/2-14-THD) | 2 | |
| 9S4185 | 33 PLUG (3/4-16-THD) | 1 | |
| 9S8752 | 34 NUT-FULL (3/8-16-THD) | 4 |
