System And Components
367-8964 LINES GP-AIR -AFTERCOOLERS/N DMC127-212
Group No: 367-8964
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1356261 | 1 CLAMP | 8 | |
| 2086135 | 2 CLIP (SLOT) | 16 | |
| 2086136 | 3 CLIP (TAB) | 16 | |
| 2556264 | 4 GASKET | 1 | |
| 2177088 | 5 HOSE | 10 | |
| 3668500 | 6 HOSE | 2 | |
| 3002396 | 7 TUBE AS | 1 | |
| 3085286 | 8 BRACKET | 1 | |
| 3085287 | 9 BRACKET | 1 | |
| 3085300 | 10 BRACKET | 1 | |
| 3085301 | 11 BRACKET | 1 | |
| 3882421 | 12 TUBE | 2 | |
| 3245885 | 13 BRACKET | 2 | |
| 3709818 | 14 TUBE AS | 1 | |
| 3709819 | 15 TUBE AS | 1 | |
| 3678931 | 16 BRACKET AS | 1 | |
| 3678932 | 17 BRACKET AS | 1 | |
| 3678933 | 18 BRACKET AS | 1 | |
| 3678934 | 19 BRACKET AS | 1 | |
| 3678937 | 20 TUBE | 1 | |
| 3678938 | 21 TUBE | 1 | |
| 3678939 | 22 TUBE AS | 1 | |
| 3678940 | 23 TUBE AS | 1 | |
| 2162211 | 24 CLAMP | 40 | |
| 3K0360 | 25 SEAL-O-RING | 2 | |
| 4L9337 | 26 BOLT (3/8-16X1.5-IN) | 16 | |
| 5M3062 | 27 BOLT (3/8-16X0.75-IN) | 20 | |
| 5M6214 | 28 PLUG (1/8-27 PTF) | 2 | |
| 5P1075 | 29 WASHER-HARD (10.2X22.5X3-MM THK) | 52 | |
| 6V8189 | 30 NUT (5/16-18-THD) | 8 | |
| 6V8801 | 31 NUT (3/8-16-THD) | 16 | |
| 8C3121 | 32 BOLT (5/16-18X1.5-IN) | 8 | |
| 8T4224 | 33 WASHER-HARD (8.8X16X2-MM THK) | 16 | |
| 9S4185 | 34 PLUG (3/4-16-THD) | 2 |
